LS Electric MAO Right-Angle Planetary Gearbox, Round Flange (1-stage)

LS Electric MAO Right-Angle Planetary Gearbox, Round Flange (1-stage)

LS Electric MAO precision planetary gearbox (basic line, helical gear, right-angle, round flange, keyed or smooth output shaft) in frames 040-160; full order code MAO<frame><stage>-<ratio><key><backlash>, motor adapter ordered separately.

Key features

  • Basic line helical-gear planetary reducer, right-angle housing
  • Spiral bevel gear right-angle stage saves installation space
  • Backlash classes: S (standard)
  • Clamp-type input with motor adapter for LS, HIGEN, Mitsubishi, Panasonic and Yaskawa servo motors
  • Lifetime grease lubrication (maintenance free), IP65

Specifications

Series MAO (Basic line)
Gear type Helical planetary
Housing Right-Angle
Output Round Flange
Frame sizes 040, 060, 080, 120, 160
Ratios 3:1 to 20:1
Efficiency (1-stage / 2-stage) >= 95% / >= 92%
Rated input speed 5,000 to 3,000 rpm
Service life 20,000 h (10,000 h continuous)
Lubrication Grease (VIGO Grease RE #0)
Protection IP65
Operating temperature -10 to +90 C
Noise <= 58 to 69 dB
Stage input 1-stage std (1A)
Source LS Electric Precision Planetary Gearbox catalog (2025.02), p. 6-7, 37, 42-45
MAO0401A-003KS Frame: 040 | Input bore: 8 mm | Ratio: 3:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-003NS Frame: 040 | Input bore: 8 mm | Ratio: 3:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-004KS Frame: 040 | Input bore: 8 mm | Ratio: 4:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-004NS Frame: 040 | Input bore: 8 mm | Ratio: 4:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-005KS Frame: 040 | Input bore: 8 mm | Ratio: 5:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-005NS Frame: 040 | Input bore: 8 mm | Ratio: 5:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-006KS Frame: 040 | Input bore: 8 mm | Ratio: 6:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-006NS Frame: 040 | Input bore: 8 mm | Ratio: 6:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-007KS Frame: 040 | Input bore: 8 mm | Ratio: 7:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-007NS Frame: 040 | Input bore: 8 mm | Ratio: 7:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-008KS Frame: 040 | Input bore: 8 mm | Ratio: 8:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-008NS Frame: 040 | Input bore: 8 mm | Ratio: 8:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-009KS Frame: 040 | Input bore: 8 mm | Ratio: 9:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-009NS Frame: 040 | Input bore: 8 mm | Ratio: 9:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A-010KS Frame: 040 | Input bore: 8 mm | Ratio: 10:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0401A-010NS Frame: 040 | Input bore: 8 mm | Ratio: 10:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-003KS Frame: 060 | Input bore: 14 mm | Ratio: 3:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-003NS Frame: 060 | Input bore: 14 mm | Ratio: 3:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-004KS Frame: 060 | Input bore: 14 mm | Ratio: 4:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-004NS Frame: 060 | Input bore: 14 mm | Ratio: 4:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-005KS Frame: 060 | Input bore: 14 mm | Ratio: 5:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-005NS Frame: 060 | Input bore: 14 mm | Ratio: 5:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-006KS Frame: 060 | Input bore: 14 mm | Ratio: 6:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-006NS Frame: 060 | Input bore: 14 mm | Ratio: 6:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-007KS Frame: 060 | Input bore: 14 mm | Ratio: 7:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-007NS Frame: 060 | Input bore: 14 mm | Ratio: 7:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-008KS Frame: 060 | Input bore: 14 mm | Ratio: 8:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-008NS Frame: 060 | Input bore: 14 mm | Ratio: 8:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-009KS Frame: 060 | Input bore: 14 mm | Ratio: 9:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-009NS Frame: 060 | Input bore: 14 mm | Ratio: 9:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-010KS Frame: 060 | Input bore: 14 mm | Ratio: 10:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-010NS Frame: 060 | Input bore: 14 mm | Ratio: 10:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-014KS Frame: 060 | Input bore: 14 mm | Ratio: 14:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-014NS Frame: 060 | Input bore: 14 mm | Ratio: 14:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0601A-020KS Frame: 060 | Input bore: 14 mm | Ratio: 20:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0601A-020NS Frame: 060 | Input bore: 14 mm | Ratio: 20:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-003KS Frame: 080 | Input bore: 19 mm | Ratio: 3:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-003NS Frame: 080 | Input bore: 19 mm | Ratio: 3:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-004KS Frame: 080 | Input bore: 19 mm | Ratio: 4:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-004NS Frame: 080 | Input bore: 19 mm | Ratio: 4:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-005KS Frame: 080 | Input bore: 19 mm | Ratio: 5:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-005NS Frame: 080 | Input bore: 19 mm | Ratio: 5:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-006KS Frame: 080 | Input bore: 19 mm | Ratio: 6:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-006NS Frame: 080 | Input bore: 19 mm | Ratio: 6:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-007KS Frame: 080 | Input bore: 19 mm | Ratio: 7:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-007NS Frame: 080 | Input bore: 19 mm | Ratio: 7:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-008KS Frame: 080 | Input bore: 19 mm | Ratio: 8:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-008NS Frame: 080 | Input bore: 19 mm | Ratio: 8:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-009KS Frame: 080 | Input bore: 19 mm | Ratio: 9:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-009NS Frame: 080 | Input bore: 19 mm | Ratio: 9:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-010KS Frame: 080 | Input bore: 19 mm | Ratio: 10:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-010NS Frame: 080 | Input bore: 19 mm | Ratio: 10:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-014KS Frame: 080 | Input bore: 19 mm | Ratio: 14:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-014NS Frame: 080 | Input bore: 19 mm | Ratio: 14:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0801A-020KS Frame: 080 | Input bore: 19 mm | Ratio: 20:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO0801A-020NS Frame: 080 | Input bore: 19 mm | Ratio: 20:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-003KS Frame: 120 | Input bore: 24 mm | Ratio: 3:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-003NS Frame: 120 | Input bore: 24 mm | Ratio: 3:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-004KS Frame: 120 | Input bore: 24 mm | Ratio: 4:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-004NS Frame: 120 | Input bore: 24 mm | Ratio: 4:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-005KS Frame: 120 | Input bore: 24 mm | Ratio: 5:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-005NS Frame: 120 | Input bore: 24 mm | Ratio: 5:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-006KS Frame: 120 | Input bore: 24 mm | Ratio: 6:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-006NS Frame: 120 | Input bore: 24 mm | Ratio: 6:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-007KS Frame: 120 | Input bore: 24 mm | Ratio: 7:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-007NS Frame: 120 | Input bore: 24 mm | Ratio: 7:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-008KS Frame: 120 | Input bore: 24 mm | Ratio: 8:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-008NS Frame: 120 | Input bore: 24 mm | Ratio: 8:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-009KS Frame: 120 | Input bore: 24 mm | Ratio: 9:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-009NS Frame: 120 | Input bore: 24 mm | Ratio: 9:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-010KS Frame: 120 | Input bore: 24 mm | Ratio: 10:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-010NS Frame: 120 | Input bore: 24 mm | Ratio: 10:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-014KS Frame: 120 | Input bore: 24 mm | Ratio: 14:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-014NS Frame: 120 | Input bore: 24 mm | Ratio: 14:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1201A-020KS Frame: 120 | Input bore: 24 mm | Ratio: 20:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1201A-020NS Frame: 120 | Input bore: 24 mm | Ratio: 20:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-003KS Frame: 160 | Input bore: 35 mm | Ratio: 3:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-003NS Frame: 160 | Input bore: 35 mm | Ratio: 3:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-004KS Frame: 160 | Input bore: 35 mm | Ratio: 4:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-004NS Frame: 160 | Input bore: 35 mm | Ratio: 4:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-005KS Frame: 160 | Input bore: 35 mm | Ratio: 5:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-005NS Frame: 160 | Input bore: 35 mm | Ratio: 5:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-006KS Frame: 160 | Input bore: 35 mm | Ratio: 6:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-006NS Frame: 160 | Input bore: 35 mm | Ratio: 6:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-007KS Frame: 160 | Input bore: 35 mm | Ratio: 7:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-007NS Frame: 160 | Input bore: 35 mm | Ratio: 7:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-008KS Frame: 160 | Input bore: 35 mm | Ratio: 8:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-008NS Frame: 160 | Input bore: 35 mm | Ratio: 8:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-009KS Frame: 160 | Input bore: 35 mm | Ratio: 9:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-009NS Frame: 160 | Input bore: 35 mm | Ratio: 9:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-010KS Frame: 160 | Input bore: 35 mm | Ratio: 10:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-010NS Frame: 160 | Input bore: 35 mm | Ratio: 10:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-014KS Frame: 160 | Input bore: 35 mm | Ratio: 14:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-014NS Frame: 160 | Input bore: 35 mm | Ratio: 14:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO1601A-020KS Frame: 160 | Input bore: 35 mm | Ratio: 20:1 | Output shaft: Keyed (K) | Backlash: S (<= 8 arcmin)
MAO1601A-020NS Frame: 160 | Input bore: 35 mm | Ratio: 20:1 | Output shaft: Smooth, no key (N) | Backlash: S (<= 8 arcmin)
MAO0401A Frame: 040 | Input bore: 8 mm | Ratio: Legacy code (specify) | Output shaft: Legacy code (specify) | Backlash: Legacy code (specify)
MAO0601A Frame: 060 | Input bore: 14 mm | Ratio: Legacy code (specify) | Output shaft: Legacy code (specify) | Backlash: Legacy code (specify)
MAO0801A Frame: 080 | Input bore: 19 mm | Ratio: Legacy code (specify) | Output shaft: Legacy code (specify) | Backlash: Legacy code (specify)
MAO1201A Frame: 120 | Input bore: 24 mm | Ratio: Legacy code (specify) | Output shaft: Legacy code (specify) | Backlash: Legacy code (specify)
MAO1601A Frame: 160 | Input bore: 35 mm | Ratio: Legacy code (specify) | Output shaft: Legacy code (specify) | Backlash: Legacy code (specify)
