• LS Electric Metasol Surge Absorbers (US / AS series)
1 1

LS Electric Metasol Surge Absorbers (US / AS series)

LS Electric Metasol Surge Absorbers (US / AS series)

LS ELECTRIC Metasol Surge Absorber accessories. | Application: Absorb coil-generated surges during contactor switching to prevent noise/malfunction in surrounding electronics. | US series: 3-pole MC-6a~150a + 4-pole MC-6a/4~18a/4 | AS series: 3-pole MC-185a~800a + 4-pole MC-22a/4~800a/4 | Variants: Varistor only / RC only / Varistor+RC | Voltage range: AC 24~440V, DC 24~125V | Ui: 1000V | Uimp: 8kV | IP20 | Connection: simply attach to coil terminals | See RFQ table for specific model.

Specifications

Ui 1000V
Uimp 8kV
Mount directly on contactor coil terminal
Standard IEC60947-4-1
US-1 US-1 surge absorber AC 24~48V | Model: US-1 | Internal: Varistor+RC | Rated voltage: AC 24~48V (AC) | Varistor V: 120V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-2 US-2 surge absorber AC 100~125V | Model: US-2 | Internal: Varistor+RC | Rated voltage: AC 100~125V (AC) | Varistor V: 270V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-3 US-3 surge absorber AC 200~240V | Model: US-3 | Internal: Varistor+RC | Rated voltage: AC 200~240V (AC) | Varistor V: 470V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-4 US-4 surge absorber DC 24~48V | Model: US-4 | Internal: Varistor+RC | Rated voltage: DC 24~48V (DC) | Varistor V: 120V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-5 US-5 surge absorber DC 100~125V | Model: US-5 | Internal: Varistor+RC | Rated voltage: DC 100~125V (DC) | Varistor V: 270V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-6 US-6 surge absorber DC 200~220V | Model: US-6 | Internal: Varistor+RC | Rated voltage: DC 200~220V (DC) | Varistor V: 470V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-11 US-11 surge absorber AC/DC 24~48V | Model: US-11 | Internal: Varistor | Rated voltage: AC/DC 24~48V (AC/DC) | Varistor V: 120V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-12 US-12 surge absorber AC/DC 100~125V | Model: US-12 | Internal: Varistor | Rated voltage: AC/DC 100~125V (AC/DC) | Varistor V: 270V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-13 US-13 surge absorber AC/DC 200~240V | Model: US-13 | Internal: Varistor | Rated voltage: AC/DC 200~240V (AC/DC) | Varistor V: 470V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-14 US-14 surge absorber AC/DC 380~440V | Model: US-14 | Internal: Varistor | Rated voltage: AC/DC 380~440V (AC/DC) | Varistor V: 1000V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-22 US-22 surge absorber AC 100~125V | Model: US-22 | Internal: RC | Rated voltage: AC 100~125V (AC) | Varistor V: - | R: 56Ω | C: 1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-1 AS-1 surge absorber AC 24~48V | Model: AS-1 | Internal: Varistor+RC | Rated voltage: AC 24~48V (AC) | Varistor V: 120V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-2 AS-2 surge absorber AC 100~125V | Model: AS-2 | Internal: Varistor+RC | Rated voltage: AC 100~125V (AC) | Varistor V: 270V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-3 AS-3 surge absorber AC 200~240V | Model: AS-3 | Internal: Varistor+RC | Rated voltage: AC 200~240V (AC) | Varistor V: 470V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-4 AS-4 surge absorber DC 24~48V | Model: AS-4 | Internal: Varistor+RC | Rated voltage: DC 24~48V (DC) | Varistor V: 120V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-5 AS-5 surge absorber DC 100~125V | Model: AS-5 | Internal: Varistor+RC | Rated voltage: DC 100~125V (DC) | Varistor V: 270V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-6 AS-6 surge absorber DC 200~220V | Model: AS-6 | Internal: Varistor+RC | Rated voltage: DC 200~220V (DC) | Varistor V: 470V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-11 AS-11 surge absorber AC/DC 24~48V | Model: AS-11 | Internal: Varistor | Rated voltage: AC/DC 24~48V (AC/DC) | Varistor V: 120V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-12 AS-12 surge absorber AC/DC 100~125V | Model: AS-12 | Internal: Varistor | Rated voltage: AC/DC 100~125V (AC/DC) | Varistor V: 270V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-13 AS-13 surge absorber AC/DC 200~240V | Model: AS-13 | Internal: Varistor | Rated voltage: AC/DC 200~240V (AC/DC) | Varistor V: 470V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-14 AS-14 surge absorber AC 380~440V | Model: AS-14 | Internal: Varistor | Rated voltage: AC 380~440V (AC) | Varistor V: 1000V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AccessoriesLS Electric
21 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric Metasol Surge Absorbers (US / AS series)

Brand LS Electric·Accessories

Available part numbers (21)

US-1, US-2, US-3, US-4, US-5, US-6, US-11, US-12, US-13, US-14 + 11 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
US-1US-1 surge absorber AC 24~48V | Model: US-1 | Internal: Varistor+RC | Rated voltage: AC 24~48V (AC) | Varistor V: 120V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-2US-2 surge absorber AC 100~125V | Model: US-2 | Internal: Varistor+RC | Rated voltage: AC 100~125V (AC) | Varistor V: 270V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-3US-3 surge absorber AC 200~240V | Model: US-3 | Internal: Varistor+RC | Rated voltage: AC 200~240V (AC) | Varistor V: 470V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-4US-4 surge absorber DC 24~48V | Model: US-4 | Internal: Varistor+RC | Rated voltage: DC 24~48V (DC) | Varistor V: 120V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-5US-5 surge absorber DC 100~125V | Model: US-5 | Internal: Varistor+RC | Rated voltage: DC 100~125V (DC) | Varistor V: 270V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-6US-6 surge absorber DC 200~220V | Model: US-6 | Internal: Varistor+RC | Rated voltage: DC 200~220V (DC) | Varistor V: 470V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-11US-11 surge absorber AC/DC 24~48V | Model: US-11 | Internal: Varistor | Rated voltage: AC/DC 24~48V (AC/DC) | Varistor V: 120V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-12US-12 surge absorber AC/DC 100~125V | Model: US-12 | Internal: Varistor | Rated voltage: AC/DC 100~125V (AC/DC) | Varistor V: 270V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-13US-13 surge absorber AC/DC 200~240V | Model: US-13 | Internal: Varistor | Rated voltage: AC/DC 200~240V (AC/DC) | Varistor V: 470V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-14US-14 surge absorber AC/DC 380~440V | Model: US-14 | Internal: Varistor | Rated voltage: AC/DC 380~440V (AC/DC) | Varistor V: 1000V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
US-22US-22 surge absorber AC 100~125V | Model: US-22 | Internal: RC | Rated voltage: AC 100~125V (AC) | Varistor V: - | R: 56Ω | C: 1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-1AS-1 surge absorber AC 24~48V | Model: AS-1 | Internal: Varistor+RC | Rated voltage: AC 24~48V (AC) | Varistor V: 120V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-2AS-2 surge absorber AC 100~125V | Model: AS-2 | Internal: Varistor+RC | Rated voltage: AC 100~125V (AC) | Varistor V: 270V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-3AS-3 surge absorber AC 200~240V | Model: AS-3 | Internal: Varistor+RC | Rated voltage: AC 200~240V (AC) | Varistor V: 470V | R: 100Ω | C: 0.1µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-4AS-4 surge absorber DC 24~48V | Model: AS-4 | Internal: Varistor+RC | Rated voltage: DC 24~48V (DC) | Varistor V: 120V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-5AS-5 surge absorber DC 100~125V | Model: AS-5 | Internal: Varistor+RC | Rated voltage: DC 100~125V (DC) | Varistor V: 270V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-6AS-6 surge absorber DC 200~220V | Model: AS-6 | Internal: Varistor+RC | Rated voltage: DC 200~220V (DC) | Varistor V: 470V | R: 100Ω | C: 0.47µF | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-11AS-11 surge absorber AC/DC 24~48V | Model: AS-11 | Internal: Varistor | Rated voltage: AC/DC 24~48V (AC/DC) | Varistor V: 120V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-12AS-12 surge absorber AC/DC 100~125V | Model: AS-12 | Internal: Varistor | Rated voltage: AC/DC 100~125V (AC/DC) | Varistor V: 270V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-13AS-13 surge absorber AC/DC 200~240V | Model: AS-13 | Internal: Varistor | Rated voltage: AC/DC 200~240V (AC/DC) | Varistor V: 470V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
AS-14AS-14 surge absorber AC 380~440V | Model: AS-14 | Internal: Varistor | Rated voltage: AC 380~440V (AC) | Varistor V: 1000V | R: - | C: - | Ui: 1000V | Uimp: 8kV | IP20 | Mount: directly on contactor coil terminal | Standard: IEC60947-4-1
