LS Electric S100 Drive Options (Option Cards and Braking Units)

Option cards and external dynamic braking units for the LS Electric S100 AC drive, including legacy part numbers kept for spares and replacement.

Key features

Plug-in option cards for S100 fieldbus and extension I/O (legacy part numbers)
Fieldbus families supported by S100: Profibus-DP, EtherNet/IP, Modbus TCP, CANopen, EtherCAT, PROFINET
Extension I/O: 2 relay outputs, 3 digital inputs, 2 analog inputs / 1 analog output
External braking units for S100 400V drives above 22 kW

Specifications

Brand	LS Electric
Compatible drive	S100 series
Built-in braking	S100 22 kW and below has a built-in braking unit
Other S100 braking units	SV370/550/750DBU-4U, LSLV0370/0750DBU-4HN/-4LN (see H100 braking units)
Selection	Confirm part number against the option or braking unit manual
Source	LS Electric S100 catalog (KR 2023.06), p. 6, 77

SV075DB-4		Category: Braking unit \| Listing: Current catalog \| Application: S100 400V 45-75 kW \| UL: Non-UL type
SV037DBH-4		Category: Braking unit \| Listing: Legacy code \| Application: 400V class, 3.7 kW \| UL: Non-UL type
SV075DBH-4		Category: Braking unit \| Listing: Legacy code \| Application: 400V class, 7.5 kW \| UL: Non-UL type
64150001		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150002		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150003		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150042		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150034		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150035		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64150025		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual
64090353		Category: Option card \| Listing: Legacy code \| Application: S100 drive \| UL: Per option manual

Drive OptionsLS Electric

11 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric S100 Drive Options (Option Cards and Braking Units)

Brand LS Electric·Drive Options

Available part numbers (11)

SV075DB-4, SV037DBH-4, SV075DBH-4, 64150001, 64150002, 64150003, 64150042, 64150034, 64150035, 64150025 + 1 more — see full table ↓

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
