LS Electric XGT XGP Power Supply Modules (AC/DC Input)

LS Electric XGT XGP Power Supply Modules (AC/DC Input)

LS Electric XGT XGP power modules mount in the power slot of XGB main and expansion bases and supply DC 5 V (and on XGP-ACF1 also DC 24 V) to the CPU and I/O modules.

Key features

  • AC 110/220 V free-voltage, AC 220 V and DC 24 V input models
  • DC 5 V output from 3 A up to 10 A for large module configurations
  • XGP-ACF1 adds a DC 24 V 0.6 A service output for sensors and I/O
  • Large-capacity XGP-AC23 / AC24 for fully loaded 12-slot bases
  • Common to XGK and XGI CPU systems on XGB-M/E bases

Specifications

Mounting Power slot of XGB-M main / XGB-E expansion base
Compatible CPUs XGK, XGI
Cooling Natural air cooling
Width note XGP-AC23 large-capacity module width 110 mm
Operating temperature 0 to 55 C
Humidity 5 to 95% RH, non-condensing
Vibration / shock IEC 61131-2
Source LS Electric XGT Series catalog (2026-07), p. 17, 148, 150
XGP-ACF1 Input voltage: AC 110/220 V | Output: DC 5 V 3 A, DC 24 V 0.6 A | Capacity class: Standard
XGP-ACF2 Input voltage: AC 110/220 V | Output: DC 5 V 6 A | Capacity class: Standard
XGP-AC23 Input voltage: AC 220 V | Output: DC 5 V 8.5 A | Capacity class: Large capacity
XGP-AC24 Input voltage: AC 220 V | Output: DC 5 V 10 A | Capacity class: Large capacity
XGP-DC42 Input voltage: DC 24 V | Output: DC 5 V 6 A | Capacity class: Standard
XGP-DC44 Input voltage: DC 24 V | Output: DC 5 V 9 A | Capacity class: Large capacity
PLC AccessoriesLS Electric
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

LS Electric XGT XGP Power Supply Modules (AC/DC Input)

Brand LS Electric·PLC Accessories

Available part numbers (6)

XGP-ACF1, XGP-ACF2, XGP-AC23, XGP-AC24, XGP-DC42, XGP-DC44

How to order

Send the LS Electric part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
XGP-ACF1Input voltage: AC 110/220 V | Output: DC 5 V 3 A, DC 24 V 0.6 A | Capacity class: Standard
XGP-ACF2Input voltage: AC 110/220 V | Output: DC 5 V 6 A | Capacity class: Standard
XGP-AC23Input voltage: AC 220 V | Output: DC 5 V 8.5 A | Capacity class: Large capacity
XGP-AC24Input voltage: AC 220 V | Output: DC 5 V 10 A | Capacity class: Large capacity
XGP-DC42Input voltage: DC 24 V | Output: DC 5 V 6 A | Capacity class: Standard
XGP-DC44Input voltage: DC 24 V | Output: DC 5 V 9 A | Capacity class: Large capacity
