MEAN WELL DLC-02 DALI-2 Controller / KNX-DALI Gateway

MEAN WELL DLC-02 DALI-2 Controller / KNX-DALI Gateway

The DLC-02 is a DALI-2 multi-master application controller, and the DLC-02-KN version adds a KNX to DALI gateway.

Key features

  • Universal 100~277 VAC input and two independent DALI bus channels with built-in bus power supply (up to 250 mA per bus)
  • Connects up to 2x64 DALI ECGs/drivers and up to 2x12 DALI input devices, with LCD display, LED indicators and buttons for local operation
  • Built-in 250 V / 10 A x4 relay; easy installation and configuration via PC software or web browser. 5-year warranty

Specifications

Input voltage 100~277 VAC
DALI channels 2
Relay 250 V / 10 A x4
Dimensions L145x W38x H22 mm
DLC-02 Function: DALI-2 controller | Input voltage: 100~277 VAC | DALI channels: 2 | Relay: 250 V / 10 A x4 | Dimensions: L145x W38x H22 mm
DLC-02-KN Function: DALI-2 controller / KNX-DALI gateway | Input voltage: 100~277 VAC | DALI channels: 2 | Relay: 250 V / 10 A x4 | Dimensions: L145x W38x H22 mm
LED Lighting ControlsMEAN WELL
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

MEAN WELL DLC-02 DALI-2 Controller / KNX-DALI Gateway

Brand MEAN WELL·LED Lighting Controls

Available part numbers (2)

DLC-02, DLC-02-KN

How to order

Send the MEAN WELL part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DLC-02Function: DALI-2 controller | Input voltage: 100~277 VAC | DALI channels: 2 | Relay: 250 V / 10 A x4 | Dimensions: L145x W38x H22 mm
DLC-02-KNFunction: DALI-2 controller / KNX-DALI gateway | Input voltage: 100~277 VAC | DALI channels: 2 | Relay: 250 V / 10 A x4 | Dimensions: L145x W38x H22 mm
