• Myunghwa Metal Pan Head Self-Drilling Screw #8 (10-100 mm)
1 1

Myunghwa Metal Pan Head Self-Drilling Screw #8 (10-100 mm)

Myunghwa Metal Pan Head Self-Drilling Screw #8 (10-100 mm)

#8 pan head self-drilling screws (no washer face) for light-gauge steel sheet 0.6-2 mm.

Key features

  • Standard application: steel sheet 0.6-2 mm
  • Pan head without washer
  • Drills and taps in one operation
  • Long lengths up to 100 mm

Specifications

Head Pan head
Drive Phillips
Point Drill point
Gauge / diameter #8 (4.2 mm)
Material Carbon steel (case-hardened)
Application Steel sheet 0.6-2 mm
Source Myunghwa Metal product list (mhs.co.kr)
810 PH Size: #8 (4.2 mm) x 10 mm | Head: Pan
838 PH Size: #8 (4.2 mm) x 38 mm | Head: Pan
850 PH Size: #8 (4.2 mm) x 50 mm | Head: Pan
864 PH Size: #8 (4.2 mm) x 64 mm | Head: Pan
875 PH Size: #8 (4.2 mm) x 75 mm | Head: Pan
8100 PH Size: #8 (4.2 mm) x 100 mm | Head: Pan
Self-Drilling ScrewsMyunghwa Metal
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Myunghwa Metal Pan Head Self-Drilling Screw #8 (10-100 mm)

Brand Myunghwa Metal·Self-Drilling Screws

Available part numbers (6)

810 PH, 838 PH, 850 PH, 864 PH, 875 PH, 8100 PH

How to order

Send the Myunghwa Metal part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
810 PHSize: #8 (4.2 mm) x 10 mm | Head: Pan
838 PHSize: #8 (4.2 mm) x 38 mm | Head: Pan
850 PHSize: #8 (4.2 mm) x 50 mm | Head: Pan
864 PHSize: #8 (4.2 mm) x 64 mm | Head: Pan
875 PHSize: #8 (4.2 mm) x 75 mm | Head: Pan
8100 PHSize: #8 (4.2 mm) x 100 mm | Head: Pan
