Samyang Reducer SUPER MAX Geared Motor, Vertical (1.5–30 kW)

Samyang Reducer SUPER MAX Geared Motor, Vertical (1.5–30 kW)

SUPER MAX vertical (flange-mounted) helical geared motors from 2 HP (1.5 kW) to 40 HP (30 kW), with ratios from 1:4 to 1:150.

Key features

  • Order code: SM + frame + motor HP + ratio + case type + reducer option R000 + motor option M001 + motor maker (3 Hyosung, 1 HiGen)
  • Frame prefix 2 = 2-stage helical (about 1:5-1:30), prefix 3 = 3-stage (about 1:33-1:150)
  • Carburized special-steel gears with ground high-speed pinions; about 30% less vibration and 10 dB lower noise than earlier models
  • Self-aligning roller and tapered roller bearings, bearing preload set with an adjusting plate
  • Flange-mounted case for direct mounting to the driven machine
  • SBB spring-applied DC brake motor and IEC motor adapter (VI) available as options

Specifications

Case type VT vertical, flange mount
Gearing Parallel-shaft helical, 2 or 3 stages
Lubrication Oil bath
Motor 3-phase TEFC IP44, class F, continuous
Supply 220/380 V, 440 V, 60 Hz
Ambient -30 to 40 C, up to 1000 m, indoor
Shaft key KS B 1311
Motor options Brake, voltage, inverter: specify
Source Samyang SUPER MAX Geared Motor catalog, p. 1-82 to 1-110
SM 2165 VT Code type: Model (dimension sheet) | Frame: 2165 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2200 VT Code type: Model (dimension sheet) | Frame: 2200 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2225 VT Code type: Model (dimension sheet) | Frame: 2225 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2255 VT Code type: Model (dimension sheet) | Frame: 2255 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2300 VT Code type: Model (dimension sheet) | Frame: 2300 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2350 VT Code type: Model (dimension sheet) | Frame: 2350 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3165 VT Code type: Model (dimension sheet) | Frame: 3165 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3200 VT Code type: Model (dimension sheet) | Frame: 3200 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3225 VT Code type: Model (dimension sheet) | Frame: 3225 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3255 VT Code type: Model (dimension sheet) | Frame: 3255 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3300 VT Code type: Model (dimension sheet) | Frame: 3300 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3350 VT Code type: Model (dimension sheet) | Frame: 3350 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2165 2HP 6.5 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:1.5-1:10
SM 2165 2HP 10 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:1.5-1:10
SM 2165 2HP 12 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 15 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 20 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 21 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 25 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 30 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 3165 2HP 35 VT R000 M001 3 Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 40 VT R000 M001 3 Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 50 VT R000 M001 3 Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 60 VT R000 M001 3 Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3225 2HP 90 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:70-1:150
SM 2165 3HP 5 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 6.5 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 10 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 12 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 15 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 20 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 21 VT R000 M001 3 Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2200 3HP 25 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2200 3HP 30 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 3200 3HP 40 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 45 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 50 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 55 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 60 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3225 3HP 70 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3200 3HP 90 VT R000 M001 3 Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3225 3HP 90 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 100 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 120 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 150 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 2200 5HP 5 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 6 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 6.5 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 7 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 8 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 10 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 15 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2200 5HP 20 VT R000 M001 3 Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2225 5HP 25 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2225 5HP 30 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 3225 5HP 35 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 40 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 45 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 50 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 60 VT R000 M001 3 Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3255 5HP 75 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 80 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 90 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 95 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 100 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 120 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 143 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3300 5HP 150 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 2225 7.5HP 4 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 5 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 8 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 10 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 15 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2225 7.5HP 20 VT R000 M001 3 Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2255 7.5HP 25 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2255 7.5HP 30 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 3255 7.5HP 33 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 35 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 40 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 45 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 50 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 60 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3300 7.5HP 70 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 75 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 80 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 90 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 100 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 120 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 150 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 2255 10HP 25 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 7.5 kW (10HP) | Ratio range: 1:12-1:30
SM 2255 10HP 30 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 7.5 kW (10HP) | Ratio range: 1:12-1:30
SM 3255 10HP 33 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 35 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 40 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 45 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 50 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 60 VT R000 M001 3 Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3300 10HP 70 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 75 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 80 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 90 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 100 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 120 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3350 10HP 150 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 2255 15HP 5 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 6 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 6.3 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 7 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 10 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 15 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2255 15HP 20 VT R000 M001 3 Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2300 15HP 25 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2300 15HP 30 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 3300 15HP 33 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 35 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 40 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 43 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 45 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 50 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 60 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3350 15HP 80 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 85 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 90 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 100 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 120 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 2300 20HP 5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:1.5-1:10
SM 2300 20HP 10 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:1.5-1:10
SM 2300 20HP 15 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 20 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 25 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 30 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 3300 20HP 33 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 35 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 40 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 43 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 45 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 50 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 60 VT R000 M001 3 Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3350 20HP 80 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 3350 20HP 85 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 3350 20HP 90 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 2300 25HP 1.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 2.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 3 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 6 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 7 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 7.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 10 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 15 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 17 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 18 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 20 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 25 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 28 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 30 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 3350 25HP 35 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 40 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 45 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 50 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 60 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3420 25HP 90 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:70-1:150
SM 2300 30HP 1.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 2.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 3 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 6 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 7 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 7.5 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 10 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 15 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 17 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 18 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 20 VT R000 M001 3 Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 25 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 28 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 30 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 3350 30HP 35 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 40 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 45 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 50 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 60 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3420 30HP 90 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:70-1:150
SM 2350 40HP 5 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 8 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 10 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 15 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 2350 40HP 17 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 2350 40HP 20 VT R000 M001 3 Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 22 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 25 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 30 VT R000 M001 3 Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3420 40HP 35 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 40 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 45 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 50 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 60 VT R000 M001 3 Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
Geared MotorsSamyang Reducer
197 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Samyang Reducer SUPER MAX Geared Motor, Vertical (1.5–30 kW)

Brand Samyang Reducer·Geared Motors

Available part numbers (197)

SM 2165 VT, SM 2200 VT, SM 2225 VT, SM 2255 VT, SM 2300 VT, SM 2350 VT, SM 3165 VT, SM 3200 VT, SM 3225 VT, SM 3255 VT + 187 more — see full table ↓

How to order

Send the Samyang Reducer part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SM 2165 VTCode type: Model (dimension sheet) | Frame: 2165 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2200 VTCode type: Model (dimension sheet) | Frame: 2200 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2225 VTCode type: Model (dimension sheet) | Frame: 2225 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2255 VTCode type: Model (dimension sheet) | Frame: 2255 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2300 VTCode type: Model (dimension sheet) | Frame: 2300 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2350 VTCode type: Model (dimension sheet) | Frame: 2350 | Stages: 2-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3165 VTCode type: Model (dimension sheet) | Frame: 3165 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3200 VTCode type: Model (dimension sheet) | Frame: 3200 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3225 VTCode type: Model (dimension sheet) | Frame: 3225 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3255 VTCode type: Model (dimension sheet) | Frame: 3255 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3300 VTCode type: Model (dimension sheet) | Frame: 3300 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 3350 VTCode type: Model (dimension sheet) | Frame: 3350 | Stages: 3-stage | Power: All ratings of frame | Ratio range: All ratios of frame
SM 2165 2HP 6.5 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:1.5-1:10
SM 2165 2HP 10 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:1.5-1:10
SM 2165 2HP 12 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 15 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 20 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 21 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 25 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 2165 2HP 30 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 1.5 kW (2HP) | Ratio range: 1:12-1:30
SM 3165 2HP 35 VT R000 M001 3Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 40 VT R000 M001 3Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 50 VT R000 M001 3Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3165 2HP 60 VT R000 M001 3Code type: Order code | Frame: 3165 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:33-1:60
SM 3225 2HP 90 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 1.5 kW (2HP) | Ratio range: 1:70-1:150
SM 2165 3HP 5 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 6.5 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 10 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:1.5-1:10
SM 2165 3HP 12 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 15 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 20 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2165 3HP 21 VT R000 M001 3Code type: Order code | Frame: 2165 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2200 3HP 25 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 2200 3HP 30 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 2.2 kW (3HP) | Ratio range: 1:12-1:30
SM 3200 3HP 40 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 45 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 50 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 55 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3200 3HP 60 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:33-1:60
SM 3225 3HP 70 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3200 3HP 90 VT R000 M001 3Code type: Order code | Frame: 3200 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3225 3HP 90 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 100 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 120 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 3255 3HP 150 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 2.2 kW (3HP) | Ratio range: 1:70-1:150
SM 2200 5HP 5 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 6 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 6.5 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 7 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 8 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 10 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:1.5-1:10
SM 2200 5HP 15 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2200 5HP 20 VT R000 M001 3Code type: Order code | Frame: 2200 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2225 5HP 25 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 2225 5HP 30 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 3.7 kW (5HP) | Ratio range: 1:12-1:30
SM 3225 5HP 35 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 40 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 45 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 50 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3225 5HP 60 VT R000 M001 3Code type: Order code | Frame: 3225 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:33-1:60
SM 3255 5HP 75 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 80 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 90 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 95 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 100 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 120 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3255 5HP 143 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 3300 5HP 150 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 3.7 kW (5HP) | Ratio range: 1:70-1:150
SM 2225 7.5HP 4 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 5 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 8 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 10 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:1.5-1:10
SM 2225 7.5HP 15 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2225 7.5HP 20 VT R000 M001 3Code type: Order code | Frame: 2225 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2255 7.5HP 25 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 2255 7.5HP 30 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:12-1:30
SM 3255 7.5HP 33 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 35 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 40 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 45 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 50 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3255 7.5HP 60 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:33-1:60
SM 3300 7.5HP 70 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 75 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 80 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 90 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 100 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 120 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 3300 7.5HP 150 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 5.5 kW (7.5HP) | Ratio range: 1:70-1:150
SM 2255 10HP 25 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 7.5 kW (10HP) | Ratio range: 1:12-1:30
SM 2255 10HP 30 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 7.5 kW (10HP) | Ratio range: 1:12-1:30
SM 3255 10HP 33 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 35 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 40 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 45 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 50 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3255 10HP 60 VT R000 M001 3Code type: Order code | Frame: 3255 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:33-1:60
SM 3300 10HP 70 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 75 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 80 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 90 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 100 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3300 10HP 120 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 3350 10HP 150 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 7.5 kW (10HP) | Ratio range: 1:70-1:150
SM 2255 15HP 5 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 6 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 6.3 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 7 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 10 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:1.5-1:10
SM 2255 15HP 15 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2255 15HP 20 VT R000 M001 3Code type: Order code | Frame: 2255 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2300 15HP 25 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 2300 15HP 30 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 11 kW (15HP) | Ratio range: 1:12-1:30
SM 3300 15HP 33 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 35 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 40 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 43 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 45 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 50 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3300 15HP 60 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:33-1:60
SM 3350 15HP 80 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 85 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 90 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 100 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 3350 15HP 120 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 11 kW (15HP) | Ratio range: 1:70-1:150
SM 2300 20HP 5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:1.5-1:10
SM 2300 20HP 10 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:1.5-1:10
SM 2300 20HP 15 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 20 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 25 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 2300 20HP 30 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 15 kW (20HP) | Ratio range: 1:12-1:30
SM 3300 20HP 33 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 35 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 40 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 43 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 45 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 50 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3300 20HP 60 VT R000 M001 3Code type: Order code | Frame: 3300 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:33-1:60
SM 3350 20HP 80 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 3350 20HP 85 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 3350 20HP 90 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 15 kW (20HP) | Ratio range: 1:70-1:150
SM 2300 25HP 1.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 2.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 3 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 6 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 7 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 7.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 10 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:1.5-1:10
SM 2300 25HP 15 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 17 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 18 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2300 25HP 20 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 25 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 28 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 2350 25HP 30 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 18.5 kW (25HP) | Ratio range: 1:12-1:30
SM 3350 25HP 35 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 40 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 45 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 50 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3350 25HP 60 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:33-1:60
SM 3420 25HP 90 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 18.5 kW (25HP) | Ratio range: 1:70-1:150
SM 2300 30HP 1.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 2.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 3 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 6 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 7 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 7.5 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 10 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:1.5-1:10
SM 2300 30HP 15 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 17 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 18 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2300 30HP 20 VT R000 M001 3Code type: Order code | Frame: 2300 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 25 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 28 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 2350 30HP 30 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 22 kW (30HP) | Ratio range: 1:12-1:30
SM 3350 30HP 35 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 40 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 45 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 50 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3350 30HP 60 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:33-1:60
SM 3420 30HP 90 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 22 kW (30HP) | Ratio range: 1:70-1:150
SM 2350 40HP 5 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 8 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 10 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:1.5-1:10
SM 2350 40HP 15 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 2350 40HP 17 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 2350 40HP 20 VT R000 M001 3Code type: Order code | Frame: 2350 | Stages: 2-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 22 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 25 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3350 40HP 30 VT R000 M001 3Code type: Order code | Frame: 3350 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:12-1:30
SM 3420 40HP 35 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 40 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 45 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 50 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60
SM 3420 40HP 60 VT R000 M001 3Code type: Order code | Frame: 3420 | Stages: 3-stage | Power: 30 kW (40HP) | Ratio range: 1:33-1:60

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Motors & Gearheads →
