Sanyo Denki San Ace 60W 9WL Splash Proof Fan (60x60x25 mm)

Sanyo Denki San Ace 60W 9WL Splash Proof Fan (60x60x25 mm)

The San Ace 60W 9WL type is an IP68-rated splash proof DC fan, 60x60x25 mm, for cooling equipment exposed to water and dust.

Key features

  • IP68 ingress protection against water and dust (motor and electronics)
  • Rated voltage 12 / 24 VDC; rated speed 6150 to 11000 min-1
  • Max. airflow up to 1.4 m3/min; max. static pressure up to 300 Pa
  • Locked rotor burnout protection and reverse polarity protection
  • PWM speed control (25 kHz) with pulse sensor output

Specifications

Series 9WL type
Product Splash Proof DC Fan
Size 60x60x25 mm
Frame Aluminum (black coating)
Ingress protection IP68
Operating temperature -20 to +70 C
Expected life (L10) 180000 h at 60 C
Motor protection Locked rotor burnout, reverse polarity
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 374-376
9WL0612P4S001 Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor, PWM
9WL0612P4J001 Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Pulse sensor, PWM
9WL0612P4H001 Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor, PWM
9WL0624P4S001 Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor, PWM
9WL0624P4J001 Voltage: 24 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Pulse sensor, PWM
9WL0624P4H001 Voltage: 24 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor, PWM
9WL0612H4002 Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Without sensor (option)
9WL0612H4D001 Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Lock sensor (option)
9WL0612J4002 Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Without sensor (option)
9WL0612J4D001 Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Lock sensor (option)
9WL0612S4002 Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Without sensor (option)
9WL0612S4D001 Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Lock sensor (option)
9WL0624H4001 Voltage: 24 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor (option)
9WL0624J4D001 Voltage: 24 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Lock sensor (option)
9WL0624S4002 Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Without sensor (option)
9WL0624S4001 Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor (option)
DC Axial FansSanyo Denki
16 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 60W 9WL Splash Proof Fan (60x60x25 mm)

Brand Sanyo Denki·DC Axial Fans

Available part numbers (16)

9WL0612P4S001, 9WL0612P4J001, 9WL0612P4H001, 9WL0624P4S001, 9WL0624P4J001, 9WL0624P4H001, 9WL0612H4002, 9WL0612H4D001, 9WL0612J4002, 9WL0612J4D001 + 6 more — see full table ↓

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9WL0612P4S001Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor, PWM
9WL0612P4J001Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Pulse sensor, PWM
9WL0612P4H001Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor, PWM
9WL0624P4S001Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor, PWM
9WL0624P4J001Voltage: 24 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Pulse sensor, PWM
9WL0624P4H001Voltage: 24 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor, PWM
9WL0612H4002Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Without sensor (option)
9WL0612H4D001Voltage: 12 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Lock sensor (option)
9WL0612J4002Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Without sensor (option)
9WL0612J4D001Voltage: 12 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Lock sensor (option)
9WL0612S4002Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Without sensor (option)
9WL0612S4D001Voltage: 12 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Lock sensor (option)
9WL0624H4001Voltage: 24 VDC | Speed: 6150 min-1 | Airflow: 0.78 m3/min | Static pressure: 97 Pa | Feature: Pulse sensor (option)
9WL0624J4D001Voltage: 24 VDC | Speed: 8650 min-1 | Airflow: 1.1 m3/min | Static pressure: 182 Pa | Feature: Lock sensor (option)
9WL0624S4002Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Without sensor (option)
9WL0624S4001Voltage: 24 VDC | Speed: 11000 min-1 | Airflow: 1.4 m3/min | Static pressure: 300 Pa | Feature: Pulse sensor (option)
