Sanyo Denki San Ace 92W 9WL Splash Proof Fan (92x92x38 mm)

Sanyo Denki San Ace 92W 9WL Splash Proof Fan (92x92x38 mm)

The San Ace 92W 9WL type is an IP68-rated splash proof DC fan, 92x92x38 mm, for cooling equipment exposed to water and dust.

Key features

  • IP68 ingress protection against water and dust (motor and electronics)
  • Rated voltage 12 / 24 / 48 VDC; rated speed 7000 to 9000 min-1
  • Max. airflow up to 3.7 m3/min; max. static pressure up to 430 Pa
  • Locked rotor burnout protection and reverse polarity protection
  • PWM speed control (25 kHz) with pulse sensor output

Specifications

Series 9WL type
Product Splash Proof DC Fan
Size 92x92x38 mm
Frame Aluminum (black coating)
Ingress protection IP68
Operating temperature -20 to +70 C
Expected life (L10) 100000 h at 60 C
Motor protection Locked rotor burnout, reverse polarity
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 393-395
9WL0912P1H001 Voltage: 12 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0912P1F001 Voltage: 12 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0924P1H001 Voltage: 24 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0924P1F001 Voltage: 24 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0948P1H601 Voltage: 48 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0948P1F601 Voltage: 48 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0924F1002 Voltage: 24 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Without sensor (option)
9WL0924H1D001 Voltage: 24 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Lock sensor (option)
DC Axial FansSanyo Denki
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 92W 9WL Splash Proof Fan (92x92x38 mm)

Brand Sanyo Denki·DC Axial Fans

Available part numbers (8)

9WL0912P1H001, 9WL0912P1F001, 9WL0924P1H001, 9WL0924P1F001, 9WL0948P1H601, 9WL0948P1F601, 9WL0924F1002, 9WL0924H1D001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9WL0912P1H001Voltage: 12 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0912P1F001Voltage: 12 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0924P1H001Voltage: 24 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0924P1F001Voltage: 24 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0948P1H601Voltage: 48 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Pulse sensor, PWM
9WL0948P1F601Voltage: 48 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Pulse sensor, PWM
9WL0924F1002Voltage: 24 VDC | Speed: 7000 min-1 | Airflow: 2.9 m3/min | Static pressure: 263 Pa | Feature: Without sensor (option)
9WL0924H1D001Voltage: 24 VDC | Speed: 9000 min-1 | Airflow: 3.7 m3/min | Static pressure: 430 Pa | Feature: Lock sensor (option)
