Sanyo Denki San Ace 120 9SX DC Fan 120x120x38 mm

Sanyo Denki San Ace 120 9SX DC Fan 120x120x38 mm

The San Ace 120 9SX is a 120x120x38 mm aluminum-frame 12 VDC high airflow fan with pulse sensor and PWM control.

Key features

  • Aluminum frame; mass 390 g
  • Printed model numbers for 12 V rated voltage
  • 12 V high airflow fan, 7400 min-1, 7.3 m3/min
  • Pulse sensor with PWM control (25 kHz)
  • Locked rotor burnout protection and reverse polarity protection
  • Compatible options: 109-019E, 109-019K, 109-1000G, 109-1000F13/F20/F30/F40

Specifications

Size 120x120x38 mm
Series San Ace 120 9SX
Material Aluminum frame, plastic impeller (UL 94V-1)
Mass 390 g
Feature Pulse sensor, PWM
Operating temp. -10 to +60 °C
Expected life 40000 h/60°C (70000 h/40°C)
Motor protection Locked rotor burnout, reverse polarity
Compatible options 109-019E, 109-019K, 109-1000G, 109-1000F13/F20/F30/F40
Source Sanyo Denki San Ace General Catalog C1152B001, p. 176-177
9SX1212P1K001 Voltage: 12 VDC (10.8 to 13.2 V) | Speed: 7400 min-1 | Airflow: 7.3 m3/min (258 CFM) | Static pressure: 480 Pa (1.93 inH2O) | SPL: 66 dB(A)
DC Axial FansSanyo Denki
1 product code available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 120 9SX DC Fan 120x120x38 mm

Brand Sanyo Denki·DC Axial Fans

Available part numbers (1)

9SX1212P1K001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9SX1212P1K001Voltage: 12 VDC (10.8 to 13.2 V) | Speed: 7400 min-1 | Airflow: 7.3 m3/min (258 CFM) | Static pressure: 480 Pa (1.93 inH2O) | SPL: 66 dB(A)
