Sanyo Denki San Ace 136RF 9RF Reversible Flow Fan dia. 136x28 mm

Sanyo Denki San Ace 136RF 9RF Reversible Flow Fan dia. 136x28 mm

The San Ace 136RF 9RF type is a dia. 136x28 mm DC reversible flow fan whose airflow direction can be switched between forward and reverse.

Key features

  • Up to 2 m3/min max. airflow and 102 Pa max. static pressure
  • Rated voltage 12 / 24 VDC (2 catalogue models)
  • Pulse sensor with PWM speed control (25 kHz PWM frequency)
  • Motor protection: Locked rotor burnout protection, Reverse polarity protection
  • Material: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)

Specifications

Size dia. 136x28 mm
Series / type San Ace 136RF 9RF type
Sensor / control Pulse sensor, PWM control
PWM frequency 25 kHz
Operating temperature -20 to +70 °C
Expected life (L10) 40000 h at 60 °C
Rated voltage 12 / 24 VDC
Mass 220 g
Max. airflow 2.0 / 2.0 m3/min
Max. static pressure 102 / 104 Pa
SPL 35 / 46 dB(A)
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 258-259
9RF1312P3H601 Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 3100 / 3100 min-1 | Current / input: 0.15 A / 1.8 W
9RF1324P3H601 Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 3100 / 3100 min-1 | Current / input: 0.09 A / 2.2 W
Reversible Flow FansSanyo Denki
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 136RF 9RF Reversible Flow Fan dia. 136x28 mm

Brand Sanyo Denki·Reversible Flow Fans

Available part numbers (2)

9RF1312P3H601, 9RF1324P3H601

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9RF1312P3H601Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 3100 / 3100 min-1 | Current / input: 0.15 A / 1.8 W
9RF1324P3H601Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 3100 / 3100 min-1 | Current / input: 0.09 A / 2.2 W
