Sanyo Denki San Ace 136RF 9RFA Reversible Flow Fan dia. 136x28 mm

Sanyo Denki San Ace 136RF 9RFA Reversible Flow Fan dia. 136x28 mm

The San Ace 136RF 9RFA type is a dia. 136x28 mm DC reversible flow fan whose airflow direction can be switched between forward and reverse.

Key features

  • Up to 2.1 m3/min max. airflow and 285 Pa max. static pressure
  • Rated voltage 12 / 24 VDC (4 catalogue models)
  • Pulse sensor with PWM speed control (25 kHz PWM frequency)
  • Motor protection: Locked rotor burnout protection, Reverse polarity protection
  • Material: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)

Specifications

Size dia. 136x28 mm
Series / type San Ace 136RF 9RFA type
Sensor / control Pulse sensor, PWM control
PWM frequency 25 kHz
Operating temperature -25 to +70 °C
Expected life (L10) 40000 h at 60 °C
Rated voltage 12 / 24 VDC
Mass 204 g
Storage temperature -30 to +70 °C (non-condensing)
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 255-257
9RFA1312P3G001 Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 5450 / 5450 min-1 | Airflow (fwd/rev): 2.10 / 2.05 m3/min | Static pressure (fwd/rev): 285 / 280 Pa | SPL (fwd/rev): 49 / 52 dB(A) | Current / input: 0.25 A / 3.00 W
9RFA1312P3H001 Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 4350 / 4350 min-1 | Airflow (fwd/rev): 1.67 / 1.63 m3/min | Static pressure (fwd/rev): 185 / 180 Pa | SPL (fwd/rev): 44 / 47 dB(A) | Current / input: 0.16 A / 1.92 W
9RFA1324P3G001 Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 5450 / 5450 min-1 | Airflow (fwd/rev): 2.10 / 2.05 m3/min | Static pressure (fwd/rev): 285 / 280 Pa | SPL (fwd/rev): 49 / 52 dB(A) | Current / input: 0.13 A / 3.12 W
9RFA1324P3H001 Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 4350 / 4350 min-1 | Airflow (fwd/rev): 1.67 / 1.63 m3/min | Static pressure (fwd/rev): 185 / 180 Pa | SPL (fwd/rev): 44 / 47 dB(A) | Current / input: 0.08 A / 1.92 W
Reversible Flow FansSanyo Denki
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 136RF 9RFA Reversible Flow Fan dia. 136x28 mm

Brand Sanyo Denki·Reversible Flow Fans

Available part numbers (4)

9RFA1312P3G001, 9RFA1312P3H001, 9RFA1324P3G001, 9RFA1324P3H001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9RFA1312P3G001Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 5450 / 5450 min-1 | Airflow (fwd/rev): 2.10 / 2.05 m3/min | Static pressure (fwd/rev): 285 / 280 Pa | SPL (fwd/rev): 49 / 52 dB(A) | Current / input: 0.25 A / 3.00 W
9RFA1312P3H001Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 4350 / 4350 min-1 | Airflow (fwd/rev): 1.67 / 1.63 m3/min | Static pressure (fwd/rev): 185 / 180 Pa | SPL (fwd/rev): 44 / 47 dB(A) | Current / input: 0.16 A / 1.92 W
9RFA1324P3G001Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 5450 / 5450 min-1 | Airflow (fwd/rev): 2.10 / 2.05 m3/min | Static pressure (fwd/rev): 285 / 280 Pa | SPL (fwd/rev): 49 / 52 dB(A) | Current / input: 0.13 A / 3.12 W
9RFA1324P3H001Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 4350 / 4350 min-1 | Airflow (fwd/rev): 1.67 / 1.63 m3/min | Static pressure (fwd/rev): 185 / 180 Pa | SPL (fwd/rev): 44 / 47 dB(A) | Current / input: 0.08 A / 1.92 W
