Sanyo Denki San Ace 40 9RA DC Fan 40x40x20 mm (Low Noise, Low Power)

Sanyo Denki San Ace 40 9RA DC Fan 40x40x20 mm (Low Noise, Low Power)

The San Ace 40 9RA type is a 40x40x20 mm DC axial fan rated at 5 / 12 / 24 VDC, delivering up to 0.22 m3/min airflow and 78 Pa static pressure.

Key features

  • San Ace 9RA series DC axial fan in a 40x40x20 mm frame
  • Rated speed 5000 to 7800 min-1; max. airflow 0.13 to 0.22 m3/min
  • Pulse sensor output as standard
  • Locked rotor burnout protection and reverse polarity protection
  • Compatible finger guards: 109-059, 109-059H

Specifications

Frame size 40x40x20 mm
Series San Ace 40 9RA type
Rated voltage 5 / 12 / 24 VDC
Sensor Pulse sensor
Frame Ribbed
Material Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)
Operating temperature -20 to +70 °C
Expected life (L10, 60 °C) 60000 h
Mass 36 g
Motor protection Locked rotor burnout protection, reverse polarity protection
Source Sanyo Denki San Ace 9RA leaflet San_Ace_40RA20_E, p. 1-2
9RA0405H6001 Voltage: 5 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0405F6001 Voltage: 5 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0405M6001 Voltage: 5 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
9RA0412H6001 Voltage: 12 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0412F6001 Voltage: 12 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0412M6001 Voltage: 12 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
9RA0424H6001 Voltage: 24 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0424F6001 Voltage: 24 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0424M6001 Voltage: 24 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
DC Axial FansSanyo Denki
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 40 9RA DC Fan 40x40x20 mm (Low Noise, Low Power)

Brand Sanyo Denki·DC Axial Fans

Available part numbers (9)

9RA0405H6001, 9RA0405F6001, 9RA0405M6001, 9RA0412H6001, 9RA0412F6001, 9RA0412M6001, 9RA0424H6001, 9RA0424F6001, 9RA0424M6001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9RA0405H6001Voltage: 5 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0405F6001Voltage: 5 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0405M6001Voltage: 5 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
9RA0412H6001Voltage: 12 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0412F6001Voltage: 12 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0412M6001Voltage: 12 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
9RA0424H6001Voltage: 24 VDC | Speed: 7800 min-1 | Airflow: 0.22 m3/min | Static pressure: 78.0 Pa
9RA0424F6001Voltage: 24 VDC | Speed: 6500 min-1 | Airflow: 0.18 m3/min | Static pressure: 54.0 Pa
9RA0424M6001Voltage: 24 VDC | Speed: 5000 min-1 | Airflow: 0.13 m3/min | Static pressure: 32.0 Pa
