Sanyo Denki San Ace 60 9CRA Counter Rotating Fan 60x60x76 mm

Sanyo Denki San Ace 60 9CRA Counter Rotating Fan 60x60x76 mm

The San Ace 60 9CRA type is a 60x60x76 mm DC counter rotating fan that pairs two contra-rotating impellers for high airflow and high static pressure.

Key features

  • Up to 2 m3/min max. airflow and 1000 Pa max. static pressure
  • Rated voltage 12 VDC (2 catalogue models)
  • Pulse sensor with PWM speed control (25 kHz PWM frequency)
  • Motor protection: Locked rotor burnout protection, Reverse polarity protection
  • Material: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)

Specifications

Size 60x60x76 mm
Series / type San Ace 60 9CRA type
Sensor / control Pulse sensor, PWM control
PWM frequency 25 kHz
Operating temperature -20 to +70 °C
Expected life (L10) 40000 h at 60 °C
Rated voltage 12 VDC
Mass 270 g
Storage temperature -30 to +70 °C (non-condensing)
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 233-234
9CRA0612P0G001 Speed (inlet/outlet): 16500 / 13000 min-1 | Airflow: 2.0 m3/min (70.6 CFM) | Static pressure: 1000 Pa (4.0 inH2O) | SPL: 66 dB(A) | Current / input: 2.3 A / 27.6 W
9CRA0612P0S001 Speed (inlet/outlet): 14000 / 11000 min-1 | Airflow: 1.7 m3/min (60.0 CFM) | Static pressure: 720 Pa (2.89 inH2O) | SPL: 63 dB(A) | Current / input: 1.5 A / 18.0 W
9CR0612S001 Legacy code (deleted / not in current catalogue) | Size: 60x60x76 mm | Voltage: 12 VDC | Speed: 11500 min-1
9CR0612H001 Legacy code (deleted / not in current catalogue) | Size: 60x60x76 mm | Voltage: 12 VDC | Speed: 10300 min-1
DC Counter Rotating FansSanyo Denki
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 60 9CRA Counter Rotating Fan 60x60x76 mm

Brand Sanyo Denki·DC Counter Rotating Fans

Available part numbers (4)

9CRA0612P0G001, 9CRA0612P0S001, 9CR0612S001, 9CR0612H001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9CRA0612P0G001Speed (inlet/outlet): 16500 / 13000 min-1 | Airflow: 2.0 m3/min (70.6 CFM) | Static pressure: 1000 Pa (4.0 inH2O) | SPL: 66 dB(A) | Current / input: 2.3 A / 27.6 W
9CRA0612P0S001Speed (inlet/outlet): 14000 / 11000 min-1 | Airflow: 1.7 m3/min (60.0 CFM) | Static pressure: 720 Pa (2.89 inH2O) | SPL: 63 dB(A) | Current / input: 1.5 A / 18.0 W
9CR0612S001Legacy code (deleted / not in current catalogue) | Size: 60x60x76 mm | Voltage: 12 VDC | Speed: 11500 min-1
9CR0612H001Legacy code (deleted / not in current catalogue) | Size: 60x60x76 mm | Voltage: 12 VDC | Speed: 10300 min-1
