Sanyo Denki San Ace 80 9CRA Counter Rotating Fan 80x80x80 mm

Sanyo Denki San Ace 80 9CRA Counter Rotating Fan 80x80x80 mm

The San Ace 80 9CRA type is a 80x80x80 mm DC counter rotating fan that pairs two contra-rotating impellers for high airflow and high static pressure.

Key features

  • Up to 4.5 m3/min max. airflow and 1150 Pa max. static pressure
  • Rated voltage 12 / 24 / 48 VDC (4 catalogue models)
  • Pulse sensor with PWM speed control (25 kHz PWM frequency)
  • Motor protection: Locked rotor burnout protection, Reverse polarity protection
  • Material: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)

Specifications

Size 80x80x80 mm
Series / type San Ace 80 9CRA type
PWM frequency 25 kHz
Operating temperature -20 to +70 °C
Expected life (L10) 40000 h at 60 °C
Rated voltage 12 / 24 / 48 VDC
Mass 450 g
Storage temperature -30 to +70 °C (non-condensing)
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 241-243; Model Index p. 646
9CRA0812P8G001 Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0812P8H001 Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 10000 / 9400 min-1 | Airflow: 3.75 m3/min (133.9 CFM) | Static pressure: 798 Pa (3.21 inH2O) | Feature: Pulse sensor, PWM control | SPL: 72 dB(A)
9CRA0824P8G001 Voltage: 24 VDC (21.6 to 26.4 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0848P8G001 Voltage: 48 VDC (40.8 to 55.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0812G8001 Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor (option) | SPL: 76 dB(A)
9CRA0812H8001 Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 10000 / 9400 min-1 | Airflow: 3.75 m3/min (133.9 CFM) | Static pressure: 798 Pa (3.21 inH2O) | Feature: Pulse sensor (option) | SPL: 72 dB(A)
9CRA0824G8D001 Voltage: 24 VDC (21.6 to 26.4 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Lock sensor (option) | SPL: 76 dB(A)
9CR0812S801 Legacy code (deleted / not in current catalogue) | Size: 80x80x80 mm | Voltage: 12 VDC | Speed: 8000 min-1
9CR0812H801 Legacy code (deleted / not in current catalogue) | Size: 80x80x80 mm | Voltage: 12 VDC | Speed: 7000 min-1
DC Counter Rotating FansSanyo Denki
9 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 80 9CRA Counter Rotating Fan 80x80x80 mm

Brand Sanyo Denki·DC Counter Rotating Fans

Available part numbers (9)

9CRA0812P8G001, 9CRA0812P8H001, 9CRA0824P8G001, 9CRA0848P8G001, 9CRA0812G8001, 9CRA0812H8001, 9CRA0824G8D001, 9CR0812S801, 9CR0812H801

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9CRA0812P8G001Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0812P8H001Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 10000 / 9400 min-1 | Airflow: 3.75 m3/min (133.9 CFM) | Static pressure: 798 Pa (3.21 inH2O) | Feature: Pulse sensor, PWM control | SPL: 72 dB(A)
9CRA0824P8G001Voltage: 24 VDC (21.6 to 26.4 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0848P8G001Voltage: 48 VDC (40.8 to 55.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor, PWM control | SPL: 76 dB(A)
9CRA0812G8001Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Pulse sensor (option) | SPL: 76 dB(A)
9CRA0812H8001Voltage: 12 VDC (10.8 to 13.2 V) | Speed (inlet/outlet): 10000 / 9400 min-1 | Airflow: 3.75 m3/min (133.9 CFM) | Static pressure: 798 Pa (3.21 inH2O) | Feature: Pulse sensor (option) | SPL: 72 dB(A)
9CRA0824G8D001Voltage: 24 VDC (21.6 to 26.4 V) | Speed (inlet/outlet): 12000 / 11300 min-1 | Airflow: 4.5 m3/min (158.9 CFM) | Static pressure: 1150 Pa (4.62 inH2O) | Feature: Lock sensor (option) | SPL: 76 dB(A)
9CR0812S801Legacy code (deleted / not in current catalogue) | Size: 80x80x80 mm | Voltage: 12 VDC | Speed: 8000 min-1
9CR0812H801Legacy code (deleted / not in current catalogue) | Size: 80x80x80 mm | Voltage: 12 VDC | Speed: 7000 min-1

Need a different model, or a part not listed here? Send us your parts list →
