Sanyo Denki San Ace 92RF 9RF Reversible Flow Fan dia. 92x38 mm

Sanyo Denki San Ace 92RF 9RF Reversible Flow Fan dia. 92x38 mm

The San Ace 92RF 9RF type is a dia. 92x38 mm DC reversible flow fan whose airflow direction can be switched between forward and reverse.

Key features

  • Up to 1.2 m3/min max. airflow and 156 Pa max. static pressure
  • Rated voltage 12 / 24 VDC (2 catalogue models)
  • Pulse sensor with PWM speed control (25 kHz PWM frequency)
  • Motor protection: Locked rotor burnout protection, Reverse polarity protection
  • Material: Frame: Plastic (Flammability: UL 94V-0), Impeller: Plastic (Flammability: UL 94V-0)

Specifications

Size dia. 92x38 mm
Series / type San Ace 92RF 9RF type
Sensor / control Pulse sensor, PWM control
PWM frequency 25 kHz
Operating temperature -20 to +70 °C
Expected life (L10) 40000 h at 60 °C
Rated voltage 12 / 24 VDC
Mass 150 g
Max. airflow 1.2 / 1.2 m3/min
Max. static pressure 156 / 146 Pa
SPL 39 / 43 dB(A)
Source Sanyo Denki San Ace General Catalog C1152B001 '25.10, p. 252-254
9RF0912P1H001 Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 5500 / 5300 min-1 | Current / input: 0.17 A / 2.0 W
9RF0924P1H001 Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 5500 / 5300 min-1 | Current / input: 0.09 A / 2.2 W
Reversible Flow FansSanyo Denki
2 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Sanyo Denki San Ace 92RF 9RF Reversible Flow Fan dia. 92x38 mm

Brand Sanyo Denki·Reversible Flow Fans

Available part numbers (2)

9RF0912P1H001, 9RF0924P1H001

How to order

Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
9RF0912P1H001Voltage: 12 VDC (10.2 to 13.8 V) | Speed (fwd/rev): 5500 / 5300 min-1 | Current / input: 0.17 A / 2.0 W
9RF0924P1H001Voltage: 24 VDC (20.4 to 27.6 V) | Speed (fwd/rev): 5500 / 5300 min-1 | Current / input: 0.09 A / 2.2 W
