    Sanyo Denki SANMOTION C Motion Controller Connector Sets

    Sanyo Denki SANMOTION C Motion Controller Connector Sets

    Genuine mating connector sets for SANMOTION C S100, S200, S300 and S500 motion controllers and modules.

    Key features

    • Power and I/O connectors for S100 (Phoenix Contact FMC/DFMC)
    • Power-I/O connector for S200 and S300 (DFMC 1,5/20-ST-3,5)
    • RS-485/1-Wire and serial/encoder connector (TE 2040008-2)
    • S500 power supply and module connector kits (Weidmuller BCF 3.81)
    • SMC-DM332 I/O connector (OMRON XG4M-4030-T)

    Specifications

    Series SANMOTION C
    Category Connector set (option)
    Applicable controllers S100 / S200 / S300 / S500
    Mounting Cable-side mating connector
    Supply Quantity as listed per model
    Source Sanyo Denki SANMOTION C S100 p. 9, S200 p. 15, S300 p. 18, S500 p. 10
    AL-01005600-01 Use: Power connector (S100) | Mfr. part no.: FMC 1,5/3-ST-3,5 | Quantity: 1
    AL-01005600-02 Use: I/O connector (S100) | Mfr. part no.: DFMC 1,5/14-ST-3,5-LR | Quantity: 1
    AL-01174555-01 Use: Power-I/O connector (S200/S300) | Mfr. part no.: DFMC 1,5/20-ST-3,5 | Quantity: 1
    AL-01139898-01 Use: Power, SMC505/507/BL570 | Mfr. part no.: BCF 3.81/04/180 SN BK BX | Quantity: 1
    AL-01139898-02 Use: Power supply connector, SMC520 | Mfr. part no.: BCF 3.81/02/180 SN BK BX | Quantity: 1
    AL-01139898-03 Use: RS-485/1-Wire, serial/encoder | Mfr. part no.: 2040008-2 | Quantity: 1
    AL-01139898-04 Use: Encoder module connectors | Mfr. part no.: BCF 3.81/04/180 SN BK BX | Quantity: 3
    AL-01139898-05 Use: Digital I/O module connectors | Mfr. part no.: BCF 3.81/04/180 SN BK BX | Quantity: 5
    AL-01139898-06 Use: Analog I/O module connectors | Mfr. part no.: BCF 3.81/04/180 SN BK BX | Quantity: 8
    AL-01210707-01 Use: I/O connector (SMC-DM332) | Mfr. part no.: XG4M-4030-T | Quantity: 1
    Servo AccessoriesSanyo Denki
    10 product codes available in this family
    Sourced direct from KoreaExport-ready supplyCompetitive pricing
    RFQ List 0 Email about this

    Need a different model, or a part not listed here? Send us your parts list →

    Sanyo Denki SANMOTION C Motion Controller Connector Sets

    Brand Sanyo Denki·Servo Accessories

    Available part numbers (10)

    AL-01005600-01, AL-01005600-02, AL-01174555-01, AL-01139898-01, AL-01139898-02, AL-01139898-03, AL-01139898-04, AL-01139898-05, AL-01139898-06, AL-01210707-01

    How to order

    Send the Sanyo Denki part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
