Siemens SITOP RED1200, SEL1200/1400, BUF1200 add-on modules

Siemens SITOP RED1200, SEL1200/1400, BUF1200 add-on modules

SITOP add-on modules in PSU6200 design provide redundancy, selective load-circuit protection and short-term buffering for SITOP power supplies.

Key features

  • RED1200 redundancy modules for decoupling two SITOP power supplies (12/24/48 V)
  • SEL1200 selectivity modules with switching characteristic, 4 or 8 channels
  • SEL1400 selectivity modules with current-limiting characteristic, 4 or 8 channels
  • SEL1200 48 V/4 x 10 A module with monitoring interface
  • BUF1200 buffer module: 300 ms at 40 A

Specifications

Brand Siemens
Product line SITOP add-on modules
Design SITOP PSU6200 design
For SITOP power supplies
Mounting DIN rail
Source Siemens Catalog KT 10.1, p. 99-139
6EP4231-7HB00-0AX0 Module: BUF1200 buffer | Voltage: 24 V DC | Rating: 300 ms at 40 A
6EP4346-7RB00-0AX0 Module: RED1200 redundancy | Voltage: 12/24/48 V DC | Rating: 20 A total (2 x 10 A)
6EP4347-7RB00-0AX0 Module: RED1200 redundancy | Voltage: 12/24/48 V DC | Rating: 40 A total (2 x 20 A)
6EP4437-7FB00-3CX0 Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 4 x 10 A, threshold 2-10 A
6EP4437-7FB00-3DX0 Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 8 x 5 A, threshold 1-5 A
6EP4438-7FB00-3DX0 Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 8 x 10 A, threshold 2-10 A
6EP4437-7EB00-3CX0 Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 4 x 10 A, threshold 2-10 A
6EP4437-7EB00-3DX0 Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 8 x 5 A, threshold 1-5 A
6EP4438-7EB00-3DX0 Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 8 x 10 A, threshold 2-10 A
6EP4448-7FB00-3CX0 Module: SEL1200 selectivity, switching | Voltage: 48 V DC | Rating: 4 x 10 A, threshold 1-10 A
Power Supply AccessoriesSiemens
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Siemens SITOP RED1200, SEL1200/1400, BUF1200 add-on modules

Brand Siemens·Power Supply Accessories

Available part numbers (10)

6EP4231-7HB00-0AX0, 6EP4346-7RB00-0AX0, 6EP4347-7RB00-0AX0, 6EP4437-7FB00-3CX0, 6EP4437-7FB00-3DX0, 6EP4438-7FB00-3DX0, 6EP4437-7EB00-3CX0, 6EP4437-7EB00-3DX0, 6EP4438-7EB00-3DX0, 6EP4448-7FB00-3CX0

How to order

Send the Siemens part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
6EP4231-7HB00-0AX0Module: BUF1200 buffer | Voltage: 24 V DC | Rating: 300 ms at 40 A
6EP4346-7RB00-0AX0Module: RED1200 redundancy | Voltage: 12/24/48 V DC | Rating: 20 A total (2 x 10 A)
6EP4347-7RB00-0AX0Module: RED1200 redundancy | Voltage: 12/24/48 V DC | Rating: 40 A total (2 x 20 A)
6EP4437-7FB00-3CX0Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 4 x 10 A, threshold 2-10 A
6EP4437-7FB00-3DX0Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 8 x 5 A, threshold 1-5 A
6EP4438-7FB00-3DX0Module: SEL1200 selectivity, switching | Voltage: 24 V DC | Rating: 8 x 10 A, threshold 2-10 A
6EP4437-7EB00-3CX0Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 4 x 10 A, threshold 2-10 A
6EP4437-7EB00-3DX0Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 8 x 5 A, threshold 1-5 A
6EP4438-7EB00-3DX0Module: SEL1400 selectivity, limiting | Voltage: 24 V DC | Rating: 8 x 10 A, threshold 2-10 A
6EP4448-7FB00-3CX0Module: SEL1200 selectivity, switching | Voltage: 48 V DC | Rating: 4 x 10 A, threshold 1-10 A
