SMC IS10 Pressure Switch (Reed Switch Type, R1/8)

SMC IS10 Pressure Switch (Reed Switch Type, R1/8)

SMC IS10 compact mechanical pressure switch with reed switch contact, R1/8 connection and AC/DC up to 100 V, also usable with modular FRL units.

Key features

  • Set pressure range 0.1 to 0.4 MPa standard or 0.1 to 0.6 MPa (-6)
  • Reed switch contact 1a, AC/DC up to 100 V, service life 5 million cycles
  • 52 mm overall length, 62 g
  • Lead wire: grommet 0.5 m standard; 3 m (L) or 5 m (Z) and MPa/psi scale (P) as suffix options; NPT thread (N) available
  • Spacer (IS10T), L-type adapter (IS10L) and modular FRL types (IS10M/IS10E) available on inquiry; contact protection box CD-P11/CD-P12

Specifications

Fluid Air and inert gas
Proof pressure 1.0 MPa
Max. operating pressure 0.7 MPa
Port size R1/8
Contact 1a reed switch
Max. contact capacity AC 2 VA, DC 2 W
Hysteresis Fixed, 0.08 MPa or less
Repeatability ±0.05 MPa or less
Ambient and fluid temperature -5 to 60°C
Enclosure IP40 equivalent
Mass 62 g
Source SMC Korea catalog (SMCKR_IS10.pdf), PDF p. 1-3
IS10-01 Set pressure range: 0.1 to 0.4 MPa | Thread sealant: Without sealant
IS10-01-6 Set pressure range: 0.1 to 0.6 MPa | Thread sealant: Without sealant
IS10-01S Set pressure range: 0.1 to 0.4 MPa | Thread sealant: With sealant
IS10-01S-6 Set pressure range: 0.1 to 0.6 MPa | Thread sealant: With sealant
Pressure SwitchesSMC
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC IS10 Pressure Switch (Reed Switch Type, R1/8)

Brand SMC·Pressure Switches

Available part numbers (4)

IS10-01, IS10-01-6, IS10-01S, IS10-01S-6

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
IS10-01Set pressure range: 0.1 to 0.4 MPa | Thread sealant: Without sealant
IS10-01-6Set pressure range: 0.1 to 0.6 MPa | Thread sealant: Without sealant
IS10-01SSet pressure range: 0.1 to 0.4 MPa | Thread sealant: With sealant
IS10-01S-6Set pressure range: 0.1 to 0.6 MPa | Thread sealant: With sealant
