SMC LECA6 Controller for Servo Motor DC24V (Step Data Input)

SMC LECA6 step data input controller (64 points) for servo motor (DC24V) LE series electric actuators such as LEF, LEY/LEYG and LES/LESH.

Key features

64 step data points, NPN or PNP parallel I/O
Incremental encoder; lock control with forced lock release terminal
Screw or DIN rail mounting (option D; DIN rail sold separately)
Listed codes are blank controllers (-BC), set up with LEC-BCW software; preset versions take the actuator part number in place of BC (e.g. LECA6N1-LEFS16A-400)
Noise filter set LEC-NFA recommended for CE/EMC compliance

Specifications

Code type	Blank controller (-BC), data set by customer
Motor	Servo motor (DC24V)
Power supply	DC24V ±10%
Parallel input / output	11 inputs / 13 outputs (photo-coupler isolated)
Encoder	Incremental
Serial communication	RS485 (LEC-T1, LEC-W2 only)
Cable length	I/O cable 5 m max., actuator cable 20 m max.
Operating temperature	0 to 40°C (no freezing)
Enclosure	IP30 (except connectors)
Mass	150 g (screw), 170 g (DIN rail)
Source	SMC Korea catalog Controllers JXC/LEC (SMCKR_JXC-_LEC-.pdf), p. 1031-1037 (PDF p. 38-44)

LECA6N-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: None
LECA6ND-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: None
LECA6N1-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 1.5 m
LECA6N1D-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 1.5 m
LECA6N3-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 3 m
LECA6N3D-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 3 m
LECA6N5-BC		Parallel I/O: NPN \| Mounting: Screw mounting \| I/O cable: 5 m
LECA6N5D-BC		Parallel I/O: NPN \| Mounting: DIN rail mounting \| I/O cable: 5 m
LECA6P-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: None
LECA6PD-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: None
LECA6P1-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 1.5 m
LECA6P1D-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 1.5 m
LECA6P3-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 3 m
LECA6P3D-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 3 m
LECA6P5-BC		Parallel I/O: PNP \| Mounting: Screw mounting \| I/O cable: 5 m
LECA6P5D-BC		Parallel I/O: PNP \| Mounting: DIN rail mounting \| I/O cable: 5 m

Electric Actuator ControllersSMC

16 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC LECA6 Controller for Servo Motor DC24V (Step Data Input)

Brand SMC·Electric Actuator Controllers

Available part numbers (16)

LECA6N-BC, LECA6ND-BC, LECA6N1-BC, LECA6N1D-BC, LECA6N3-BC, LECA6N3D-BC, LECA6N5-BC, LECA6N5D-BC, LECA6P-BC, LECA6PD-BC + 6 more — see full table ↓
