SMC LEY Battery-less Absolute Rod Type Electric Actuator (16-40)

SMC LEY rod type electric actuator with battery-less absolute encoder step motor (DC24V), sizes 16 to 40, with top-mounted parallel or in-line motor.

Key features

Battery-less absolute encoder: position retained at power off, no backup battery maintenance
Pushing force up to 1,058 N (LEY40, lead 4); three screw leads per size
Motor cover (C) or lock with motor cover (W) selected in the code; in-line motor cover direction D1 to D4 on size 16
Rod end male thread (M) and mounting (L foot, F rod flange, G head flange, D double clevis; brackets shipped loose) are suffix options
Controller (JXC51/61 step data input; JXCE1/91/P1/D1/L1/M1 EtherCAT, EtherNet/IP, PROFINET, DeviceNet, IO-Link, CC-Link direct input), robot actuator cable length (R1/R3/R5/R8/RA/RB/RC = 1.5 to 20 m) and I/O cable are ordered as suffixes, not listed

Specifications

Drive	Ball screw + belt (parallel), ball screw (in-line)
Guide	Sliding bushing (piston rod)
Repeatability	±0.02 mm
Lost motion	0.1 mm or less
Max. acceleration/deceleration	3,000 mm/s²
Pushing speed	50 mm/s or less (16), 35 (25), 30 (32, 40)
Motor size	28 (16), 42 (25), 56.4 (32, 40)
Motor	Battery-less absolute encoder step motor (servo/DC24V)
Encoder	Battery-less absolute (position held at power off)
Power supply voltage	DC24V ±10%
Source	SMC Korea catalog Battery-less Absolute Encoder Type LE Series (SMCKR_Batteryless_LE__.pdf), p. 61-63 (PDF p. 62-64)

LEY16EA-30C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16EA-30W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16EA-50C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16EA-50W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16EA-100C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16EA-100W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16EA-150C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16EA-150W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16EA-200C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16EA-200W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16EA-250C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16EA-250W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16EA-300C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16EA-300W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16EB-30C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16EB-30W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16EB-50C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16EB-50W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16EB-100C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16EB-100W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16EB-150C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16EB-150W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16EB-200C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16EB-200W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16EB-250C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16EB-250W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16EB-300C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16EB-300W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16EC-30C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16EC-30W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16EC-50C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16EC-50W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16EC-100C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16EC-100W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16EC-150C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16EC-150W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16EC-200C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16EC-200W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16EC-250C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16EC-250W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16EC-300C		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16EC-300W		Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D1EA-30C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D1EA-30W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D1EA-50C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D1EA-50W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D1EA-100C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D1EA-100W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D1EA-150C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D1EA-150W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D1EA-200C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D1EA-200W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D1EA-250C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D1EA-250W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D1EA-300C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D1EA-300W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D1EB-30C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D1EB-30W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D1EB-50C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D1EB-50W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D1EB-100C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D1EB-100W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D1EB-150C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D1EB-150W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D1EB-200C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D1EB-200W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D1EB-250C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D1EB-250W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D1EB-300C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D1EB-300W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D1EC-30C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D1EC-30W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D1EC-50C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D1EC-50W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D1EC-100C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D1EC-100W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D1EC-150C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D1EC-150W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D1EC-200C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D1EC-200W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D1EC-250C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D1EC-250W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D1EC-300C		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D1EC-300W		Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D2EA-30C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D2EA-30W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D2EA-50C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D2EA-50W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D2EA-100C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D2EA-100W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D2EA-150C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D2EA-150W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D2EA-200C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D2EA-200W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D2EA-250C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D2EA-250W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D2EA-300C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D2EA-300W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D2EB-30C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D2EB-30W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D2EB-50C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D2EB-50W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D2EB-100C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D2EB-100W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D2EB-150C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D2EB-150W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D2EB-200C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D2EB-200W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D2EB-250C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D2EB-250W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D2EB-300C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D2EB-300W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D2EC-30C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D2EC-30W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D2EC-50C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D2EC-50W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D2EC-100C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D2EC-100W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D2EC-150C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D2EC-150W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D2EC-200C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D2EC-200W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D2EC-250C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D2EC-250W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D2EC-300C		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D2EC-300W		Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D3EA-30C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D3EA-30W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D3EA-50C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D3EA-50W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D3EA-100C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D3EA-100W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D3EA-150C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D3EA-150W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D3EA-200C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D3EA-200W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D3EA-250C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D3EA-250W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D3EA-300C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D3EA-300W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D3EB-30C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D3EB-30W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D3EB-50C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D3EB-50W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D3EB-100C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D3EB-100W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D3EB-150C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D3EB-150W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D3EB-200C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D3EB-200W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D3EB-250C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D3EB-250W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D3EB-300C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D3EB-300W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D3EC-30C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D3EC-30W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D3EC-50C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D3EC-50W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D3EC-100C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D3EC-100W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D3EC-150C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D3EC-150W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D3EC-200C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D3EC-200W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D3EC-250C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D3EC-250W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D3EC-300C		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D3EC-300W		Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D4EA-30C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D4EA-30W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D4EA-50C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D4EA-50W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D4EA-100C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D4EA-100W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D4EA-150C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D4EA-150W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D4EA-200C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D4EA-200W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D4EA-250C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D4EA-250W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D4EA-300C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D4EA-300W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D4EB-30C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D4EB-30W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D4EB-50C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D4EB-50W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D4EB-100C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D4EB-100W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D4EB-150C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D4EB-150W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D4EB-200C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D4EB-200W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D4EB-250C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D4EB-250W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D4EB-300C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D4EB-300W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY16D4EC-30C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY16D4EC-30W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY16D4EC-50C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY16D4EC-50W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY16D4EC-100C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY16D4EC-100W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY16D4EC-150C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY16D4EC-150W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY16D4EC-200C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY16D4EC-200W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY16D4EC-250C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY16D4EC-250W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY16D4EC-300C		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY16D4EC-300W		Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25EA-30C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25EA-30W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25EA-50C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25EA-50W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25EA-100C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25EA-100W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25EA-150C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25EA-150W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25EA-200C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25EA-200W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25EA-250C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25EA-250W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25EA-300C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25EA-300W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25EA-350C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25EA-350W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25EA-400C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25EA-400W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY25EB-30C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25EB-30W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25EB-50C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25EB-50W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25EB-100C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25EB-100W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25EB-150C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25EB-150W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25EB-200C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25EB-200W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25EB-250C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25EB-250W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25EB-300C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25EB-300W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25EB-350C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25EB-350W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25EB-400C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25EB-400W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY25EC-30C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25EC-30W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25EC-50C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25EC-50W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25EC-100C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25EC-100W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25EC-150C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25EC-150W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25EC-200C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25EC-200W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25EC-250C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25EC-250W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25EC-300C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25EC-300W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25EC-350C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25EC-350W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25EC-400C		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25EC-400W		Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY25DEA-30C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25DEA-30W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25DEA-50C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25DEA-50W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25DEA-100C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25DEA-100W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25DEA-150C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25DEA-150W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25DEA-200C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25DEA-200W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25DEA-250C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25DEA-250W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25DEA-300C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25DEA-300W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25DEA-350C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25DEA-350W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25DEA-400C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25DEA-400W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY25DEB-30C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25DEB-30W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25DEB-50C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25DEB-50W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25DEB-100C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25DEB-100W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25DEB-150C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25DEB-150W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25DEB-200C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25DEB-200W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25DEB-250C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25DEB-250W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25DEB-300C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25DEB-300W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25DEB-350C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25DEB-350W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25DEB-400C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25DEB-400W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY25DEC-30C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY25DEC-30W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY25DEC-50C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY25DEC-50W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY25DEC-100C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY25DEC-100W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY25DEC-150C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY25DEC-150W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY25DEC-200C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY25DEC-200W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY25DEC-250C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY25DEC-250W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY25DEC-300C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY25DEC-300W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY25DEC-350C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY25DEC-350W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY25DEC-400C		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY25DEC-400W		Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32EA-30C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32EA-30W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32EA-50C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32EA-50W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32EA-100C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32EA-100W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32EA-150C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32EA-150W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32EA-200C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32EA-200W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32EA-250C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32EA-250W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32EA-300C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32EA-300W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32EA-350C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32EA-350W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32EA-400C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32EA-400W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32EA-450C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32EA-450W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32EA-500C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32EA-500W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY32EB-30C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32EB-30W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32EB-50C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32EB-50W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32EB-100C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32EB-100W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32EB-150C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32EB-150W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32EB-200C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32EB-200W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32EB-250C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32EB-250W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32EB-300C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32EB-300W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32EB-350C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32EB-350W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32EB-400C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32EB-400W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32EB-450C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32EB-450W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32EB-500C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32EB-500W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY32EC-30C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32EC-30W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32EC-50C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32EC-50W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32EC-100C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32EC-100W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32EC-150C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32EC-150W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32EC-200C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32EC-200W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32EC-250C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32EC-250W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32EC-300C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32EC-300W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32EC-350C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32EC-350W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32EC-400C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32EC-400W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32EC-450C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32EC-450W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32EC-500C		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32EC-500W		Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY32DEA-30C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32DEA-30W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32DEA-50C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32DEA-50W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32DEA-100C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32DEA-100W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32DEA-150C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32DEA-150W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32DEA-200C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32DEA-200W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32DEA-250C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32DEA-250W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32DEA-300C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32DEA-300W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32DEA-350C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32DEA-350W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32DEA-400C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32DEA-400W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32DEA-450C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32DEA-450W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32DEA-500C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32DEA-500W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY32DEB-30C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32DEB-30W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32DEB-50C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32DEB-50W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32DEB-100C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32DEB-100W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32DEB-150C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32DEB-150W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32DEB-200C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32DEB-200W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32DEB-250C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32DEB-250W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32DEB-300C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32DEB-300W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32DEB-350C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32DEB-350W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32DEB-400C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32DEB-400W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32DEB-450C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32DEB-450W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32DEB-500C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32DEB-500W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY32DEC-30C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY32DEC-30W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY32DEC-50C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY32DEC-50W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY32DEC-100C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY32DEC-100W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY32DEC-150C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY32DEC-150W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY32DEC-200C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY32DEC-200W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY32DEC-250C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY32DEC-250W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY32DEC-300C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY32DEC-300W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY32DEC-350C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY32DEC-350W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY32DEC-400C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY32DEC-400W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY32DEC-450C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY32DEC-450W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY32DEC-500C		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY32DEC-500W		Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40EA-30C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40EA-30W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40EA-50C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40EA-50W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40EA-100C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40EA-100W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40EA-150C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40EA-150W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40EA-200C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40EA-200W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40EA-250C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40EA-250W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40EA-300C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40EA-300W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40EA-350C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40EA-350W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40EA-400C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40EA-400W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40EA-450C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40EA-450W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40EA-500C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40EA-500W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40EB-30C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40EB-30W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40EB-50C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40EB-50W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40EB-100C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40EB-100W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40EB-150C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40EB-150W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40EB-200C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40EB-200W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40EB-250C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40EB-250W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40EB-300C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40EB-300W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40EB-350C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40EB-350W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40EB-400C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40EB-400W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40EB-450C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40EB-450W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40EB-500C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40EB-500W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40EC-30C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40EC-30W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40EC-50C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40EC-50W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40EC-100C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40EC-100W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40EC-150C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40EC-150W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40EC-200C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40EC-200W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40EC-250C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40EC-250W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40EC-300C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40EC-300W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40EC-350C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40EC-350W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40EC-400C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40EC-400W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40EC-450C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40EC-450W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40EC-500C		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40EC-500W		Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40DEA-30C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40DEA-30W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40DEA-50C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40DEA-50W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40DEA-100C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40DEA-100W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40DEA-150C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40DEA-150W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40DEA-200C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40DEA-200W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40DEA-250C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40DEA-250W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40DEA-300C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40DEA-300W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40DEA-350C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40DEA-350W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40DEA-400C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40DEA-400W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40DEA-450C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40DEA-450W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40DEA-500C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40DEA-500W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40DEB-30C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40DEB-30W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40DEB-50C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40DEB-50W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40DEB-100C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40DEB-100W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40DEB-150C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40DEB-150W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40DEB-200C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40DEB-200W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40DEB-250C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40DEB-250W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40DEB-300C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40DEB-300W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40DEB-350C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40DEB-350W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40DEB-400C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40DEB-400W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40DEB-450C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40DEB-450W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40DEB-500C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40DEB-500W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
LEY40DEC-30C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
LEY40DEC-30W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
LEY40DEC-50C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
LEY40DEC-50W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
LEY40DEC-100C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
LEY40DEC-100W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
LEY40DEC-150C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
LEY40DEC-150W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
LEY40DEC-200C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
LEY40DEC-200W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
LEY40DEC-250C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
LEY40DEC-250W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
LEY40DEC-300C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
LEY40DEC-300W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
LEY40DEC-350C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
LEY40DEC-350W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
LEY40DEC-400C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
LEY40DEC-400W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
LEY40DEC-450C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
LEY40DEC-450W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
LEY40DEC-500C		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
LEY40DEC-500W		Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover

Electric ActuatorsSMC

582 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC LEY Battery-less Absolute Rod Type Electric Actuator (16-40)

Brand SMC·Electric Actuators

Available part numbers (582)

LEY16EA-30C, LEY16EA-30W, LEY16EA-50C, LEY16EA-50W, LEY16EA-100C, LEY16EA-100W, LEY16EA-150C, LEY16EA-150W, LEY16EA-200C, LEY16EA-200W + 572 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	LEY16EA-30C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16EA-30W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16EA-50C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16EA-50W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16EA-100C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16EA-100W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16EA-150C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16EA-150W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16EA-200C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16EA-200W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16EA-250C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16EA-250W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16EA-300C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16EA-300W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16EB-30C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16EB-30W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16EB-50C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16EB-50W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16EB-100C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16EB-100W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16EB-150C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16EB-150W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16EB-200C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16EB-200W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16EB-250C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16EB-250W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16EB-300C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16EB-300W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16EC-30C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16EC-30W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16EC-50C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16EC-50W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16EC-100C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16EC-100W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16EC-150C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16EC-150W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16EC-200C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16EC-200W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16EC-250C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16EC-250W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16EC-300C	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16EC-300W	Size: 16 \| Motor mounting: Top side parallel \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D1EA-30C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D1EA-30W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D1EA-50C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D1EA-50W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D1EA-100C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D1EA-100W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D1EA-150C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D1EA-150W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D1EA-200C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D1EA-200W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D1EA-250C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D1EA-250W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D1EA-300C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D1EA-300W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D1EB-30C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D1EB-30W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D1EB-50C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D1EB-50W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D1EB-100C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D1EB-100W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D1EB-150C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D1EB-150W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D1EB-200C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D1EB-200W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D1EB-250C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D1EB-250W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D1EB-300C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D1EB-300W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D1EC-30C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D1EC-30W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D1EC-50C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D1EC-50W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D1EC-100C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D1EC-100W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D1EC-150C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D1EC-150W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D1EC-200C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D1EC-200W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D1EC-250C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D1EC-250W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D1EC-300C	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D1EC-300W	Size: 16 \| Motor mounting: In-line, cover left \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D2EA-30C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D2EA-30W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D2EA-50C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D2EA-50W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D2EA-100C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D2EA-100W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D2EA-150C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D2EA-150W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D2EA-200C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D2EA-200W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D2EA-250C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D2EA-250W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D2EA-300C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D2EA-300W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D2EB-30C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D2EB-30W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D2EB-50C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D2EB-50W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D2EB-100C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D2EB-100W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D2EB-150C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D2EB-150W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D2EB-200C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D2EB-200W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D2EB-250C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D2EB-250W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D2EB-300C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D2EB-300W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D2EC-30C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D2EC-30W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D2EC-50C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D2EC-50W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D2EC-100C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D2EC-100W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D2EC-150C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D2EC-150W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D2EC-200C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D2EC-200W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D2EC-250C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D2EC-250W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D2EC-300C	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D2EC-300W	Size: 16 \| Motor mounting: In-line, cover right \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D3EA-30C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D3EA-30W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D3EA-50C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D3EA-50W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D3EA-100C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D3EA-100W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D3EA-150C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D3EA-150W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D3EA-200C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D3EA-200W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D3EA-250C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D3EA-250W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D3EA-300C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D3EA-300W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D3EB-30C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D3EB-30W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D3EB-50C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D3EB-50W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D3EB-100C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D3EB-100W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D3EB-150C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D3EB-150W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D3EB-200C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D3EB-200W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D3EB-250C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D3EB-250W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D3EB-300C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D3EB-300W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D3EC-30C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D3EC-30W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D3EC-50C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D3EC-50W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D3EC-100C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D3EC-100W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D3EC-150C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D3EC-150W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D3EC-200C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D3EC-200W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D3EC-250C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D3EC-250W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D3EC-300C	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D3EC-300W	Size: 16 \| Motor mounting: In-line, cover top \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D4EA-30C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D4EA-30W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D4EA-50C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D4EA-50W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D4EA-100C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D4EA-100W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D4EA-150C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D4EA-150W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D4EA-200C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D4EA-200W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D4EA-250C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D4EA-250W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D4EA-300C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D4EA-300W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 10 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D4EB-30C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D4EB-30W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D4EB-50C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D4EB-50W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D4EB-100C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D4EB-100W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D4EB-150C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D4EB-150W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D4EB-200C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D4EB-200W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D4EB-250C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D4EB-250W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D4EB-300C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D4EB-300W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY16D4EC-30C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY16D4EC-30W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY16D4EC-50C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY16D4EC-50W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY16D4EC-100C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY16D4EC-100W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY16D4EC-150C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY16D4EC-150W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY16D4EC-200C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY16D4EC-200W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY16D4EC-250C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY16D4EC-250W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY16D4EC-300C	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY16D4EC-300W	Size: 16 \| Motor mounting: In-line, cover bottom \| Lead: 2.5 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25EA-30C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25EA-30W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25EA-50C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25EA-50W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25EA-100C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25EA-100W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25EA-150C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25EA-150W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25EA-200C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25EA-200W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25EA-250C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25EA-250W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25EA-300C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25EA-300W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25EA-350C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25EA-350W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25EA-400C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25EA-400W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY25EB-30C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25EB-30W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25EB-50C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25EB-50W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25EB-100C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25EB-100W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25EB-150C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25EB-150W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25EB-200C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25EB-200W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25EB-250C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25EB-250W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25EB-300C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25EB-300W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25EB-350C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25EB-350W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25EB-400C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25EB-400W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY25EC-30C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25EC-30W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25EC-50C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25EC-50W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25EC-100C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25EC-100W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25EC-150C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25EC-150W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25EC-200C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25EC-200W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25EC-250C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25EC-250W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25EC-300C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25EC-300W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25EC-350C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25EC-350W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25EC-400C	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25EC-400W	Size: 25 \| Motor mounting: Top side parallel \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY25DEA-30C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25DEA-30W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25DEA-50C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25DEA-50W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25DEA-100C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25DEA-100W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25DEA-150C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25DEA-150W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25DEA-200C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25DEA-200W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25DEA-250C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25DEA-250W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25DEA-300C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25DEA-300W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25DEA-350C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25DEA-350W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25DEA-400C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25DEA-400W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 12 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY25DEB-30C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25DEB-30W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25DEB-50C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25DEB-50W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25DEB-100C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25DEB-100W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25DEB-150C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25DEB-150W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25DEB-200C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25DEB-200W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25DEB-250C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25DEB-250W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25DEB-300C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25DEB-300W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25DEB-350C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25DEB-350W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25DEB-400C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25DEB-400W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 6 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY25DEC-30C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY25DEC-30W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY25DEC-50C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY25DEC-50W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY25DEC-100C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY25DEC-100W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY25DEC-150C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY25DEC-150W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY25DEC-200C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY25DEC-200W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY25DEC-250C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY25DEC-250W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY25DEC-300C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY25DEC-300W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY25DEC-350C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY25DEC-350W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY25DEC-400C	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY25DEC-400W	Size: 25 \| Motor mounting: In-line (straight) \| Lead: 3 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32EA-30C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32EA-30W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32EA-50C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32EA-50W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32EA-100C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32EA-100W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32EA-150C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32EA-150W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32EA-200C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32EA-200W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32EA-250C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32EA-250W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32EA-300C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32EA-300W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32EA-350C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32EA-350W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32EA-400C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32EA-400W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32EA-450C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32EA-450W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32EA-500C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32EA-500W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY32EB-30C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32EB-30W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32EB-50C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32EB-50W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32EB-100C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32EB-100W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32EB-150C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32EB-150W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32EB-200C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32EB-200W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32EB-250C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32EB-250W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32EB-300C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32EB-300W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32EB-350C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32EB-350W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32EB-400C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32EB-400W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32EB-450C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32EB-450W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32EB-500C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32EB-500W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY32EC-30C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32EC-30W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32EC-50C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32EC-50W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32EC-100C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32EC-100W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32EC-150C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32EC-150W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32EC-200C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32EC-200W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32EC-250C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32EC-250W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32EC-300C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32EC-300W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32EC-350C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32EC-350W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32EC-400C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32EC-400W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32EC-450C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32EC-450W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32EC-500C	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32EC-500W	Size: 32 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY32DEA-30C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32DEA-30W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32DEA-50C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32DEA-50W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32DEA-100C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32DEA-100W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32DEA-150C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32DEA-150W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32DEA-200C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32DEA-200W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32DEA-250C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32DEA-250W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32DEA-300C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32DEA-300W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32DEA-350C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32DEA-350W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32DEA-400C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32DEA-400W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32DEA-450C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32DEA-450W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32DEA-500C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32DEA-500W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY32DEB-30C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32DEB-30W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32DEB-50C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32DEB-50W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32DEB-100C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32DEB-100W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32DEB-150C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32DEB-150W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32DEB-200C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32DEB-200W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32DEB-250C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32DEB-250W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32DEB-300C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32DEB-300W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32DEB-350C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32DEB-350W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32DEB-400C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32DEB-400W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32DEB-450C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32DEB-450W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32DEB-500C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32DEB-500W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY32DEC-30C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY32DEC-30W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY32DEC-50C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY32DEC-50W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY32DEC-100C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY32DEC-100W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY32DEC-150C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY32DEC-150W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY32DEC-200C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY32DEC-200W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY32DEC-250C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY32DEC-250W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY32DEC-300C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY32DEC-300W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY32DEC-350C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY32DEC-350W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY32DEC-400C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY32DEC-400W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY32DEC-450C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY32DEC-450W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY32DEC-500C	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY32DEC-500W	Size: 32 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40EA-30C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40EA-30W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40EA-50C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40EA-50W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40EA-100C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40EA-100W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40EA-150C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40EA-150W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40EA-200C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40EA-200W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40EA-250C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40EA-250W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40EA-300C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40EA-300W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40EA-350C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40EA-350W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40EA-400C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40EA-400W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40EA-450C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40EA-450W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40EA-500C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40EA-500W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40EB-30C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40EB-30W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40EB-50C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40EB-50W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40EB-100C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40EB-100W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40EB-150C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40EB-150W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40EB-200C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40EB-200W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40EB-250C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40EB-250W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40EB-300C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40EB-300W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40EB-350C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40EB-350W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40EB-400C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40EB-400W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40EB-450C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40EB-450W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40EB-500C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40EB-500W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40EC-30C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40EC-30W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40EC-50C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40EC-50W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40EC-100C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40EC-100W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40EC-150C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40EC-150W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40EC-200C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40EC-200W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40EC-250C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40EC-250W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40EC-300C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40EC-300W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40EC-350C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40EC-350W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40EC-400C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40EC-400W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40EC-450C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40EC-450W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40EC-500C	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40EC-500W	Size: 40 \| Motor mounting: Top side parallel \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40DEA-30C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40DEA-30W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40DEA-50C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40DEA-50W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40DEA-100C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40DEA-100W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40DEA-150C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40DEA-150W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40DEA-200C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40DEA-200W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40DEA-250C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40DEA-250W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40DEA-300C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40DEA-300W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40DEA-350C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40DEA-350W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40DEA-400C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40DEA-400W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40DEA-450C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40DEA-450W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40DEA-500C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40DEA-500W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 16 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40DEB-30C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40DEB-30W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40DEB-50C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40DEB-50W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40DEB-100C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40DEB-100W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40DEB-150C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40DEB-150W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40DEB-200C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40DEB-200W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40DEB-250C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40DEB-250W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40DEB-300C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40DEB-300W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40DEB-350C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40DEB-350W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40DEB-400C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40DEB-400W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40DEB-450C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40DEB-450W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40DEB-500C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40DEB-500W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 8 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover
	LEY40DEC-30C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With motor cover
	LEY40DEC-30W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 30 mm \| Motor option: With lock and motor cover
	LEY40DEC-50C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With motor cover
	LEY40DEC-50W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 50 mm \| Motor option: With lock and motor cover
	LEY40DEC-100C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With motor cover
	LEY40DEC-100W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 100 mm \| Motor option: With lock and motor cover
	LEY40DEC-150C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With motor cover
	LEY40DEC-150W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 150 mm \| Motor option: With lock and motor cover
	LEY40DEC-200C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With motor cover
	LEY40DEC-200W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 200 mm \| Motor option: With lock and motor cover
	LEY40DEC-250C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With motor cover
	LEY40DEC-250W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 250 mm \| Motor option: With lock and motor cover
	LEY40DEC-300C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With motor cover
	LEY40DEC-300W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 300 mm \| Motor option: With lock and motor cover
	LEY40DEC-350C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With motor cover
	LEY40DEC-350W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 350 mm \| Motor option: With lock and motor cover
	LEY40DEC-400C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With motor cover
	LEY40DEC-400W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 400 mm \| Motor option: With lock and motor cover
	LEY40DEC-450C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With motor cover
	LEY40DEC-450W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 450 mm \| Motor option: With lock and motor cover
	LEY40DEC-500C	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With motor cover
	LEY40DEC-500W	Size: 40 \| Motor mounting: In-line (straight) \| Lead: 4 mm \| Stroke: 500 mm \| Motor option: With lock and motor cover

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →

Item added to your cart

SMC LEY Battery-less Absolute Rod Type Electric Actuator (16-40)
