• SMC PF3W3 Digital Flow Monitor for Water (3-Color Display)
1 1

SMC PF3W3 Digital Flow Monitor for Water (3-Color Display)

SMC PF3W3 Digital Flow Monitor for Water (3-Color Display)

SMC PF3W3 series panel-mount 3-color digital flow monitor for PF3W5 remote flow sensors with analog 1-5 V output.

Key features

  • Remote monitor for PF3W5 sensor units with 1-5 V analog output (-1 or -1T)
  • Ten output combinations: NPN/PNP switch outputs with analog voltage/current or external input
  • Displays flow and, with a temperature-sensor model, temperature on OUT2
  • Options not expanded: power/output lead wire omitted (N), panel mount adapter (T), front cover + adapter (V), e-con connector (C)
  • Calibration certificate (A) available; CE, UKCA, UL (CSA), RoHS

Specifications

Applicable sensor PF3W5 series, analog 1-5 V output
Power supply DC12 to 24 V +/-10%
Mounting Panel mount
Display 3-color 2-screen LCD
Standards CE, UKCA, UL (CSA), RoHS
Unit SI fixed (M): L/min, L, C
Source SMC Korea catalog (SMCKR_PF3W.pdf), p. 31-32 (PDF p. 32-33)
PF3W30A-M Type: Remote monitor unit | Output: NPN + NPN | Unit: SI (L/min, C)
PF3W30B-M Type: Remote monitor unit | Output: PNP + PNP | Unit: SI (L/min, C)
PF3W30C-M Type: Remote monitor unit | Output: NPN + analog 1-5 V | Unit: SI (L/min, C)
PF3W30D-M Type: Remote monitor unit | Output: NPN + analog 4-20 mA | Unit: SI (L/min, C)
PF3W30E-M Type: Remote monitor unit | Output: PNP + analog 1-5 V | Unit: SI (L/min, C)
PF3W30F-M Type: Remote monitor unit | Output: PNP + analog 4-20 mA | Unit: SI (L/min, C)
PF3W30G-M Type: Remote monitor unit | Output: NPN + external input | Unit: SI (L/min, C)
PF3W30H-M Type: Remote monitor unit | Output: PNP + external input | Unit: SI (L/min, C)
PF3W30J-M Type: Remote monitor unit | Output: Analog 1-5 V + analog 1-5 V | Unit: SI (L/min, C)
PF3W30K-M Type: Remote monitor unit | Output: Analog 4-20 mA + analog 4-20 mA | Unit: SI (L/min, C)
Flow SwitchesSMC
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC PF3W3 Digital Flow Monitor for Water (3-Color Display)

Brand SMC·Flow Switches

Available part numbers (10)

PF3W30A-M, PF3W30B-M, PF3W30C-M, PF3W30D-M, PF3W30E-M, PF3W30F-M, PF3W30G-M, PF3W30H-M, PF3W30J-M, PF3W30K-M

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PF3W30A-MType: Remote monitor unit | Output: NPN + NPN | Unit: SI (L/min, C)
PF3W30B-MType: Remote monitor unit | Output: PNP + PNP | Unit: SI (L/min, C)
PF3W30C-MType: Remote monitor unit | Output: NPN + analog 1-5 V | Unit: SI (L/min, C)
PF3W30D-MType: Remote monitor unit | Output: NPN + analog 4-20 mA | Unit: SI (L/min, C)
PF3W30E-MType: Remote monitor unit | Output: PNP + analog 1-5 V | Unit: SI (L/min, C)
PF3W30F-MType: Remote monitor unit | Output: PNP + analog 4-20 mA | Unit: SI (L/min, C)
PF3W30G-MType: Remote monitor unit | Output: NPN + external input | Unit: SI (L/min, C)
PF3W30H-MType: Remote monitor unit | Output: PNP + external input | Unit: SI (L/min, C)
PF3W30J-MType: Remote monitor unit | Output: Analog 1-5 V + analog 1-5 V | Unit: SI (L/min, C)
PF3W30K-MType: Remote monitor unit | Output: Analog 4-20 mA + analog 4-20 mA | Unit: SI (L/min, C)
