SMC PFG200 3-Screen 4-Channel Flow Monitor

SMC PFG200 3-Screen 4-Channel Flow Monitor

SMC PFG200 series 3-screen flow monitor that accepts up to four analog flow sensors (PF2A, PF2W/PF3W, PF2D) and provides five switch outputs or IO-Link.

Key features

  • Connects up to 4 flow sensors (1-5 V voltage input, e-CON connectors)
  • Compatible sensors: PF2A air, PF2W/PF3W water and PF2D pure water/chemical flow switches
  • I/O: NPN or PNP 5 outputs + external input (PFG200/201) or IO-Link + 4 outputs (PFG202/203)
  • Front panel IP65 when panel mounted; 3-screen display shows value, label and set value
  • Suffix options: panel mount adapter (A), front cover + adapter (B), sensor connectors x4 (4C/4D), power cable 2 m standard or none (N)

Specifications

Power supply DC12 to 24V ±10% (IO-Link: DC18 to 30V)
Current consumption 55 mA or less
Sensor inputs 4, voltage 1-5 V
Sensor supply current Max. 110 mA per input (440 mA total)
Switch output NPN or PNP open collector, 5 outputs, max. 80 mA
Response time 5 ms or less
Enclosure Front IP65 (panel mount), others IP40
IO-Link V1.1, COM2 (38.4 kbps)
Standards CE/UKCA, UL (CSA)
Mass 51 g (without cable)
Unit SI unit fixed (M)
Source SMC Korea catalog CAT.KS100-157A (SMCKR_PFG200.pdf), p. 8-10 (PDF p. 9-11)
PFG200-M I/O: NPN 5 outputs + external input | Output type: NPN | IO-Link: No
PFG201-M I/O: PNP 5 outputs + external input | Output type: PNP | IO-Link: No
PFG202-M I/O: IO-Link + NPN 4 outputs | Output type: NPN | IO-Link: Yes
PFG203-M I/O: IO-Link + PNP 4 outputs | Output type: PNP | IO-Link: Yes
Flow SwitchesSMC
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC PFG200 3-Screen 4-Channel Flow Monitor

Brand SMC·Flow Switches

Available part numbers (4)

PFG200-M, PFG201-M, PFG202-M, PFG203-M

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PFG200-MI/O: NPN 5 outputs + external input | Output type: NPN | IO-Link: No
PFG201-MI/O: PNP 5 outputs + external input | Output type: PNP | IO-Link: No
PFG202-MI/O: IO-Link + NPN 4 outputs | Output type: NPN | IO-Link: Yes
PFG203-MI/O: IO-Link + PNP 4 outputs | Output type: PNP | IO-Link: Yes
