SMC PFG300 Digital Flow Monitor (3-Screen, for PF3A7H)

SMC PFG300 Digital Flow Monitor (3-Screen, for PF3A7H)

SMC PFG300 series 3-screen remote digital flow monitor for PF3A7H flow switches, with voltage (PFG300) or current (PFG310) sensor input.

Key features

  • Separate monitor unit displaying flow from PF3A7H direct-piping and modular flow switches
  • Input: voltage 1-5 V (PFG300) or current 4-20 mA (PFG310)
  • Two NPN/PNP switch outputs plus analog voltage (RT), analog current (SV) or copy function (XY)
  • Accessories as suffix options: power/output lead wire (L), brackets (A1/A2), panel mount adapter (B, D), sensor connector (C)
  • Unit switching or SI unit fixed (M); calibration certificate on order

Specifications

Power supply voltage DC12 to 24V ±10% (DC24V with PF3A7H)
Current consumption 25 mA or less
Display accuracy ±0.5% F.S. ±1 digit
Repeatability ±0.1% F.S. ±1 digit
Max. load current 80 mA
Response time 3 ms or less
Applicable flow switches PF3A7R5H to PF3A712H
Source SMC Korea catalog CAT.KS100-117E (SMCKR_PF3A7_H.pdf), p. 37-38 (PDF p. 38-39)
PFG300-RT Input: Voltage input | Output: 2 switch + analog voltage | For sensor: PF3A7H-CS/ES/L3
PFG300-SV Input: Voltage input | Output: 2 switch + analog current | For sensor: PF3A7H-CS/ES/L3
PFG300-XY Input: Voltage input | Output: 2 switch + copy function | For sensor: PF3A7H-CS/ES/L3
PFG310-RT Input: Current input | Output: 2 switch + analog voltage | For sensor: PF3A7H-DS/FS/L4
PFG310-SV Input: Current input | Output: 2 switch + analog current | For sensor: PF3A7H-DS/FS/L4
PFG310-XY Input: Current input | Output: 2 switch + copy function | For sensor: PF3A7H-DS/FS/L4
Flow SwitchesSMC
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC PFG300 Digital Flow Monitor (3-Screen, for PF3A7H)

Brand SMC·Flow Switches

Available part numbers (6)

PFG300-RT, PFG300-SV, PFG300-XY, PFG310-RT, PFG310-SV, PFG310-XY

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PFG300-RTInput: Voltage input | Output: 2 switch + analog voltage | For sensor: PF3A7H-CS/ES/L3
PFG300-SVInput: Voltage input | Output: 2 switch + analog current | For sensor: PF3A7H-CS/ES/L3
PFG300-XYInput: Voltage input | Output: 2 switch + copy function | For sensor: PF3A7H-CS/ES/L3
PFG310-RTInput: Current input | Output: 2 switch + analog voltage | For sensor: PF3A7H-DS/FS/L4
PFG310-SVInput: Current input | Output: 2 switch + analog current | For sensor: PF3A7H-DS/FS/L4
PFG310-XYInput: Current input | Output: 2 switch + copy function | For sensor: PF3A7H-DS/FS/L4
