SMC PFGM302 3-Screen Digital Flow Monitor (for PF2M7)

SMC PFGM302 3-Screen Digital Flow Monitor (for PF2M7)

SMC PFGM302 series 3-screen remote digital flow monitor for PF2M7 flow switches, accepting voltage (PFGM302) or current (PFGM312) analog sensor input.

Key features

  • Remote monitor unit for PF2M7 analog-output flow switches (0.01 to 200 L/min ranges)
  • Input: 1-5 V voltage (PFGM302, for PF2M7 C/E output) or 4-20 mA current (PFGM312, for D/F output)
  • Two NPN/PNP selectable switch outputs plus analog voltage (RT), analog current (SV) or copy function (XY)
  • 3-screen LCD: 5-digit main display (red/green) and 9-digit sub display; 3 ms response
  • Suffix options: power/output lead wire 2 m (L), bracket A/B (A1/A2), panel mount adapter (B, D), sensor connector (C); manual/calibration certificate (Y/K/T)

Specifications

Power supply voltage DC12 to 24V ±10%
Current consumption 25 mA or less
Display accuracy ±0.5% F.S. ± min. display unit
Repeatability ±0.1% F.S. ±1 digit
Max. load current 80 mA
Response time 3 ms or less
Sensor connection e-CON connector
Enclosure IP40
Standards CE/UKCA, UL (CSA)
Unit SI unit fixed (M)
Source SMC Korea catalog CAT.KS100-127D (SMCKR_PF2M7-L.pdf), p. 29-30 (PDF p. 32-33)
PFGM302-RT-M Input: Voltage input | Output: 2 switch + analog voltage | For sensor: PF2M7 C/E output
PFGM302-SV-M Input: Voltage input | Output: 2 switch + analog current | For sensor: PF2M7 C/E output
PFGM302-XY-M Input: Voltage input | Output: 2 switch + copy function | For sensor: PF2M7 C/E output
PFGM312-RT-M Input: Current input | Output: 2 switch + analog voltage | For sensor: PF2M7 D/F output
PFGM312-SV-M Input: Current input | Output: 2 switch + analog current | For sensor: PF2M7 D/F output
PFGM312-XY-M Input: Current input | Output: 2 switch + copy function | For sensor: PF2M7 D/F output
Flow SwitchesSMC
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC PFGM302 3-Screen Digital Flow Monitor (for PF2M7)

Brand SMC·Flow Switches

Available part numbers (6)

PFGM302-RT-M, PFGM302-SV-M, PFGM302-XY-M, PFGM312-RT-M, PFGM312-SV-M, PFGM312-XY-M

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PFGM302-RT-MInput: Voltage input | Output: 2 switch + analog voltage | For sensor: PF2M7 C/E output
PFGM302-SV-MInput: Voltage input | Output: 2 switch + analog current | For sensor: PF2M7 C/E output
PFGM302-XY-MInput: Voltage input | Output: 2 switch + copy function | For sensor: PF2M7 C/E output
PFGM312-RT-MInput: Current input | Output: 2 switch + analog voltage | For sensor: PF2M7 D/F output
PFGM312-SV-MInput: Current input | Output: 2 switch + analog current | For sensor: PF2M7 D/F output
PFGM312-XY-MInput: Current input | Output: 2 switch + copy function | For sensor: PF2M7 D/F output
