SMC PSE300A 3-Screen Digital Pressure Sensor Controller

SMC PSE300A 3-Screen Digital Pressure Sensor Controller

SMC PSE300A series 3-screen digital display controller for one PSE series pressure sensor, with 2 switch outputs and analog or copy-function output.

Key features

  • Voltage input (PSE30xA) or current input (PSE31xA); applicable to PSE53x, PSE54x, PSE550, PSE56x, PSE57x sensors
  • Outputs NPN/PNP selectable; output digit sets factory setting (NPN or PNP) and analog voltage/current or copy function
  • Switch output modes: hysteresis, window comparator, error output; auto-shift input
  • Option 1: L = lead wire with connector 2 m (ZS-46-5L); Option 2: A = bracket, B = panel mount adapter, D = panel adapter + front cover; Option 3: C = sensor connector ZS-28-C
  • Unit selection type or fixed SI units (-M)

Specifications

Number of inputs 1
Power supply DC12-24V ±10%, ripple 10% or less
Current consumption 35 mA or less
Display accuracy ±0.5% F.S. ±1 digit
Repeatability ±0.1% F.S. ±1 digit
Switch outputs 2, max. 80 mA, DC30V
Response time 1.5 ms or less (chattering filter selectable)
Enclosure IP40
Operating temperature 0 to 50°C
Mass 25 g
Standards CE/UKCA, UL/CSA (E216656)
Source SMC Korea catalog CAT.KS100-56D PSE Series (SMCKR_PSE.pdf), p. 44-51 (PDF p. 47-54)
PSE300A Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: With unit selection function
PSE300A-M Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE303A Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: With unit selection function
PSE303A-M Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE301A Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: With unit selection function
PSE301A-M Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE304A Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: With unit selection function
PSE304A-M Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE306A Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: With unit selection function
PSE306A-M Input: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: SI units only (kPa, MPa, Pa)
PSE310A Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: With unit selection function
PSE310A-M Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE313A Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: With unit selection function
PSE313A-M Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE311A Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: With unit selection function
PSE311A-M Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE314A Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: With unit selection function
PSE314A-M Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE316A Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: With unit selection function
PSE316A-M Input: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: SI units only (kPa, MPa, Pa)
Pressure SwitchesSMC
20 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SMC PSE300A 3-Screen Digital Pressure Sensor Controller

Brand SMC·Pressure Switches

Available part numbers (20)

PSE300A, PSE300A-M, PSE303A, PSE303A-M, PSE301A, PSE301A-M, PSE304A, PSE304A-M, PSE306A, PSE306A-M + 10 more — see full table ↓

How to order

Send the SMC part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PSE300AInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: With unit selection function
PSE300A-MInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE303AInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: With unit selection function
PSE303A-MInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE301AInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: With unit selection function
PSE301A-MInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE304AInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: With unit selection function
PSE304A-MInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE306AInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: With unit selection function
PSE306A-MInput: Voltage 1-5 V | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: SI units only (kPa, MPa, Pa)
PSE310AInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: With unit selection function
PSE310A-MInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE313AInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: With unit selection function
PSE313A-MInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog voltage (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE311AInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: With unit selection function
PSE311A-MInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (NPN) | Units: SI units only (kPa, MPa, Pa)
PSE314AInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: With unit selection function
PSE314A-MInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + analog current (PNP) | Units: SI units only (kPa, MPa, Pa)
PSE316AInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: With unit selection function
PSE316A-MInput: Current 4-20 mA | Output (factory setting): NPN/PNP 2 outputs + copy function | Units: SI units only (kPa, MPa, Pa)
