SMC PSE540 Pressure Sensor/Switch (Compact Air, Analog / IO-Link)

SMC PSE540 Pressure Sensor/Switch (Compact Air, Analog / IO-Link)

SMC PSE540 series compact pressure sensor/switch for air and non-corrosive gases, available as 1-5 V analog output type or IO-Link / 1 switch output type.

Key features

  • Pressure ranges: positive 0 to 1 MPa, vacuum 0 to -101 kPa, compound -100 to 100 kPa; standard ±2% F.S. or high-accuracy (A) ±1% F.S.
  • Seven port styles: M3, M5, R1/8 with M5 female, ø4/ø6 reducer, M5 female pipe with or without mounting hole (NPT1/8 N01 on order)
  • Analog type option C2: controller connector included (ZS-28-C)
  • IO-Link type (-L) switches between PNP/NPN; NPN (-N) / PNP (-P) 1-output versions are ordered with a factory set-value suffix (e.g. PSE540-M3-NS-P0055)
  • Lead wire termination: flying leads standard, S = M12 4-pin connector, 500 mm (IO-Link/switch types)

Specifications

Fluid Air, non-corrosive gas, non-flammable gas
Power supply DC12-24V ±10%, ripple 10% or less
Current consumption 15 mA or less
Proof pressure 1.5 MPa (PSE540), 500 kPa (PSE541/543)
Repeatability ±0.2% F.S.
Enclosure IP40
Operating temperature 0 to 50°C (storage -20 to 70°C)
Sensor cable Oil-resistant vinyl cabtyre, 3-core, 3 m
Wetted parts Sensing element silicon, O-ring NBR
Standards CE/UKCA, UL/CSA (E216656)
Source SMC Korea catalog CAT.KS100-56D PSE Series (SMCKR_PSE.pdf), p. 9-12 (PDF p. 12-15)
PSE540-M3 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE540-M5 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE540-01 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE540-R04 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE540-R06 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE540-IM5 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE540-IM5H Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE540A-M3 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE540A-M5 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE540A-01 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE540A-R04 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE540A-R06 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE540A-IM5 Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE540A-IM5H Output: Analog 1-5 V | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
PSE541-M3 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE541-M5 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE541-01 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE541-R04 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE541-R06 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE541-IM5 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE541-IM5H Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE541A-M3 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE541A-M5 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE541A-01 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE541A-R04 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE541A-R06 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE541A-IM5 Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE541A-IM5H Output: Analog 1-5 V | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
PSE543-M3 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE543-M5 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE543-01 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE543-R04 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE543-R06 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE543-IM5 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE543-IM5H Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE543A-M3 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE543A-M5 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE543A-01 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE543A-R04 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE543A-R06 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE543A-IM5 Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE543A-IM5H Output: Analog 1-5 V | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
PSE540-M3-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE540-M5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE540-01-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE540-R04-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE540-R06-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE540-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE540-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE540A-M3-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE540A-M5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE540A-01-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE540A-R04-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE540A-R06-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE540A-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE540A-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to 1 MPa (positive) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
PSE541-M3-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE541-M5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE541-01-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE541-R04-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE541-R06-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE541-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE541-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE541A-M3-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE541A-M5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE541A-01-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE541A-R04-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE541A-R06-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE541A-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE541A-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: 0 to -101 kPa (vacuum) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
PSE543-M3-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M3x0.5
PSE543-M5-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5x0.8
PSE543-01-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: R1/8 (with M5 female)
PSE543-R04-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: ø4 reducer
PSE543-R06-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: ø6 reducer
PSE543-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5 female thread pipe
PSE543-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±2% F.S. | Port: M5 female pipe, with mounting hole
PSE543A-M3-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M3x0.5
PSE543A-M5-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5x0.8
PSE543A-01-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: R1/8 (with M5 female)
PSE543A-R04-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: ø4 reducer
PSE543A-R06-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: ø6 reducer
PSE543A-IM5-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5 female thread pipe
PSE543A-IM5H-L Output: IO-Link / 1 switch output | Rated pressure range: -100 to 100 kPa (compound) | Accuracy: ±1% F.S. | Port: M5 female pipe, with mounting hole
