SPG GX Inter-Decimal Gearheads 1/10 (60-90 mm)

SPG GX Inter-Decimal Gearheads 1/10 (60-90 mm)

SPG GX inter-decimal (middle) gearheads with 1/10 reduction, mounted between the motor and the main gearhead to extend the reduction ratio beyond 1/200-1/250.

Key features

  • Fits between motor and S6/S7/S8/S9 gearhead of the same frame size
  • Total ratio = gearhead ratio x 10; permissible torque is limited (e.g. 15 kg·cm with 3 W, 300 kg·cm with S9D heads)
  • 90 mm versions in H or L impact type matching the motor; -S versions for flange-type (60-120 W) gearheads
  • Ball bearing construction

Specifications

Gear type GX inter-decimal (middle) gear
Ratio 1/10
Bearing Ball bearing
Use Between motor and main gearhead
Frame sizes 60, 70, 80, 90 mm square
Weight 0.18 kg (60 mm) to 0.65 kg (90 mm -S)
Source SPG Standard AC Geared Motor catalog, p. 4-61
S6GX10B Frame: 60 mm | Impact type: - | Mounting: Standard
S7GX10B Frame: 70 mm | Impact type: - | Mounting: Standard
S8GX10B Frame: 80 mm | Impact type: - | Mounting: Standard
S9GX10BH Frame: 90 mm | Impact type: H (heavy impact) | Mounting: Standard
S9GX10BL Frame: 90 mm | Impact type: L (light impact) | Mounting: Standard
S9GX10BH-S Frame: 90 mm | Impact type: H (heavy impact) | Mounting: Flange type (-S)
S9GX10BL-S Frame: 90 mm | Impact type: L (light impact) | Mounting: Flange type (-S)
GearheadsSPG
7 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG GX Inter-Decimal Gearheads 1/10 (60-90 mm)

Brand SPG·Gearheads

Available part numbers (7)

S6GX10B, S7GX10B, S8GX10B, S9GX10BH, S9GX10BL, S9GX10BH-S, S9GX10BL-S

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S6GX10BFrame: 60 mm | Impact type: - | Mounting: Standard
S7GX10BFrame: 70 mm | Impact type: - | Mounting: Standard
S8GX10BFrame: 80 mm | Impact type: - | Mounting: Standard
S9GX10BHFrame: 90 mm | Impact type: H (heavy impact) | Mounting: Standard
S9GX10BLFrame: 90 mm | Impact type: L (light impact) | Mounting: Standard
S9GX10BH-SFrame: 90 mm | Impact type: H (heavy impact) | Mounting: Flange type (-S)
S9GX10BL-SFrame: 90 mm | Impact type: L (light impact) | Mounting: Flange type (-S)
