SPG S10I 104 mm Induction Motors (200 W, Lead Wire/Terminal Box)

SPG S10I 104 mm Induction Motors (200 W, Lead Wire/Terminal Box)

SPG S10I200 series 104 mm square, 200 W, 4-pole continuous-duty AC induction motor in lead-wire and terminal-box versions for the S10KV gearhead.

Key features

  • 200 W output in a 104 mm frame, 4 poles, continuous rating
  • Shaft types: G pinion (for S10KV gearhead), D-cut or keyed round shaft
  • Voltage codes A (1-ph 100-115 V), B (1-ph 200-230 V) and T (3-ph 200-230 V)
  • -T suffix: terminal box with cabtyre cable for improved sealing (IP54)
  • Class B insulation (130 C); UL, CE and CCC approvals for global use

Specifications

Frame size 104 mm square
Output 200 W
Poles 4
Duty Continuous
Rated speed 1250-1600 rpm (by voltage/frequency)
Rated torque 12.2-15.6 kgf-cm
Insulation class B (130 C)
Matching gearhead S10KV (3-180:1)
Source SPG Standard AC Geared Motor catalog, p. 299-303
S10I200GA Shaft: Pinion (gear type) | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200GB Shaft: Pinion (gear type) | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200GT Shaft: Pinion (gear type) | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200DA Shaft: D-cut round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200DB Shaft: D-cut round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200DT Shaft: D-cut round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200KA Shaft: Keyed round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200KB Shaft: Keyed round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200KT Shaft: Keyed round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200GA-T Shaft: Pinion (gear type) | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200GB-T Shaft: Pinion (gear type) | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200GT-T Shaft: Pinion (gear type) | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
S10I200DA-T Shaft: D-cut round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200DB-T Shaft: D-cut round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200DT-T Shaft: D-cut round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
S10I200KA-T Shaft: Keyed round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200KB-T Shaft: Keyed round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200KT-T Shaft: Keyed round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
AC Induction MotorsSPG
18 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG S10I 104 mm Induction Motors (200 W, Lead Wire/Terminal Box)

Brand SPG·AC Induction Motors

Available part numbers (18)

S10I200GA, S10I200GB, S10I200GT, S10I200DA, S10I200DB, S10I200DT, S10I200KA, S10I200KB, S10I200KT, S10I200GA-T + 8 more — see full table ↓

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
S10I200GAShaft: Pinion (gear type) | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200GBShaft: Pinion (gear type) | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200GTShaft: Pinion (gear type) | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200DAShaft: D-cut round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200DBShaft: D-cut round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200DTShaft: D-cut round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200KAShaft: Keyed round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Lead wire
S10I200KBShaft: Keyed round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Lead wire
S10I200KTShaft: Keyed round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Lead wire
S10I200GA-TShaft: Pinion (gear type) | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200GB-TShaft: Pinion (gear type) | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200GT-TShaft: Pinion (gear type) | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
S10I200DA-TShaft: D-cut round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200DB-TShaft: D-cut round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200DT-TShaft: D-cut round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
S10I200KA-TShaft: Keyed round | Voltage: 1-ph 100 V 50/60 Hz, 110/115 V 60 Hz | Rated current: 2.85-3.45 A | Capacitor: 47 / 40 uF | Connection: Terminal box (IP54)
S10I200KB-TShaft: Keyed round | Voltage: 1-ph 200 V 50/60, 220 V 60, 230 V 50/60 | Rated current: 1.36-1.66 A | Capacitor: 12 / 10 uF | Connection: Terminal box (IP54)
S10I200KT-TShaft: Keyed round | Voltage: 3-ph 200/220 V 50/60 Hz, 230 V 60 Hz | Rated current: 0.95-1.10 A | Capacitor: None (3-phase) | Connection: Terminal box (IP54)
