SPG SHAS/SHBS Origin Sensor Sets for Hollow Rotary Tables

SPG SHAS/SHBS Origin Sensor Sets for Hollow Rotary Tables

SPG origin (home) sensor set for SHA and SHB hollow rotary tables, with photo micro sensor, connector cable, sensor bracket, dog and mounting screws.

Key features

  • Complete kit for return-to-home operation: sensor, connector cable, bracket, dog and screws
  • NPN (open collector, max. 100 mA) or PNP (open collector, max. 50 mA) output versions
  • Normally open / normally closed logic selectable by wiring
  • Red detection indicator lamp
  • Use shielded cable grounded at one end when extending the sensor cable beyond 2 m

Specifications

Power supply DC 5-24 V +/-10%, ripple 10% p-p max.
Current consumption 35 mA max. (NPN), 30 mA max. (PNP)
Indicator Detection display (red)
Sensor logic Normally open / normally closed (by wiring)
Installation Ambient below 40 deg C, motor surface below 90 deg C
Not available for SHB 060
Source SPG Hollow Rotary Table catalog, p. 16-19, 32-34
SHAS-A Sensor output: NPN | For: SHA 060 | Photo micro sensor: OMRON EE-SX672A
SHAS-AY Sensor output: PNP | For: SHA 060 | Photo micro sensor: OMRON EE-SX672R
SHAS-B Sensor output: NPN | For: SHA 085/130/170/200 | Photo micro sensor: OMRON EE-SX673A
SHAS-BY Sensor output: PNP | For: SHA 085/130/170/200 | Photo micro sensor: OMRON EE-SX673R
SHBS-B Sensor output: NPN | For: SHB 100/130/200/275 | Photo micro sensor: OMRON EE-SX672A
SHBS-BY Sensor output: PNP | For: SHB 100/130/200/275 | Photo micro sensor: OMRON EE-SX672R
Motor AccessoriesSPG
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

SPG SHAS/SHBS Origin Sensor Sets for Hollow Rotary Tables

Brand SPG·Motor Accessories

Available part numbers (6)

SHAS-A, SHAS-AY, SHAS-B, SHAS-BY, SHBS-B, SHBS-BY

How to order

Send the SPG part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SHAS-ASensor output: NPN | For: SHA 060 | Photo micro sensor: OMRON EE-SX672A
SHAS-AYSensor output: PNP | For: SHA 060 | Photo micro sensor: OMRON EE-SX672R
SHAS-BSensor output: NPN | For: SHA 085/130/170/200 | Photo micro sensor: OMRON EE-SX673A
SHAS-BYSensor output: PNP | For: SHA 085/130/170/200 | Photo micro sensor: OMRON EE-SX673R
SHBS-BSensor output: NPN | For: SHB 100/130/200/275 | Photo micro sensor: OMRON EE-SX672A
SHBS-BYSensor output: PNP | For: SHB 100/130/200/275 | Photo micro sensor: OMRON EE-SX672R
