WON ST WBS / WBAS / WBCS Tapped Linear Shafts (dia. 10-50 mm)

WON ST WBS / WBAS / WBCS Tapped Linear Shafts (dia. 10-50 mm)

WON ST WBS/WBAS/WBCS linear motion shafts with tapped holes along the shaft line, used on shaft line supports with open-type ball bushings, diameter 10 to 50 mm.

Key features

  • Tapped holes along the axis let the shaft be bolted to an ST/STU line support to prevent deflection and vibration
  • WBS: high carbon steel / SUJ-2; WBAS: SUS440C stainless; WBCS: hard chrome plated
  • Standard tap size, tap pitch and end distance per diameter (M4 to M10, pitch 100-300 mm)
  • Outside diameter tolerance g6, h5 or h6 as a code field
  • Model number: series - diameter tolerance x length - tap x pitch - end distance (e.g. WBS-16h6x2000-M5x200-100)
  • Other tap pitches and end distances on request

Specifications

Construction Solid shaft, tapped along shaft line
Surface hardness Induction hardened
Finish Precision ground
Tolerance classes g6, h5, h6
Mating support ST, STU, S-ST, S-STU shaft line supports
Standard lengths 1000-3000 mm (by diameter)
Source WON ST catalog (Korean ed. W202206), p. 293-294
WBS-10g6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-10h5x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-10h6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12g6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12h5x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12h6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13g6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13h5x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13h6x1000-M4x100-50 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-16g6x1000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x1200-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x1500-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x2000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1200-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1500-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x2000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1200-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1500-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x2000-M5x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-20g6x1000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x1200-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x1500-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x2000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x3000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1200-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1500-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x2000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x3000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1200-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1500-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x2000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x3000-M6x150-75 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-25g6x1000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x1200-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x1500-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x2000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x3000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1200-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1500-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x2000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x3000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1200-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1500-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x2000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x3000-M6x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-30g6x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1200-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1500-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x2000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x3000-M8x200-100 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-40g6x1000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x1200-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x1500-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x2000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x3000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1200-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1500-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x2000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x3000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1200-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1500-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x2000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x3000-M8x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-50g6x1000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x1200-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x1500-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x2000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x3000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1200-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1500-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x2000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x3000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1200-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1500-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x2000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x3000-M10x300-150 Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-10g6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-10h5x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-10h6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12g6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12h5x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12h6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13g6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13h5x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13h6x1000-M4x100-50 Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-16g6x1000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x1200-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x1500-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x2000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1200-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1500-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x2000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1200-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1500-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x2000-M5x150-75 Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-20g6x1000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x1200-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x1500-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x2000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x3000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1200-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1500-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x2000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x3000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1200-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1500-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x2000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x3000-M6x150-75 Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-25g6x1000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x1200-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x1500-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x2000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x3000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1200-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1500-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x2000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x3000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1200-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1500-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x2000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x3000-M6x200-100 Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-30g6x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1200-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1500-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x2000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x3000-M8x200-100 Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-40g6x1000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x1200-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x1500-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x2000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x3000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1200-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1500-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x2000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x3000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1200-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1500-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x2000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x3000-M8x300-150 Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-50g6x1000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x1200-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x1500-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x2000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x3000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1200-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1500-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x2000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x3000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1200-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1500-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x2000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x3000-M10x300-150 Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-10g6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-10h5x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-10h6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12g6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12h5x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12h6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13g6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13h5x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13h6x1000-M4x100-50 Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-16g6x1000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x1200-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x1500-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x2000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1200-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1500-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x2000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1200-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1500-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x2000-M5x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-20g6x1000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x1200-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x1500-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x2000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x3000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1200-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1500-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x2000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x3000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1200-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1500-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x2000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x3000-M6x150-75 Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-25g6x1000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x1200-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x1500-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x2000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x3000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1200-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1500-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x2000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x3000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1200-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1500-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x2000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x3000-M6x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-30g6x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1200-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1500-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x2000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x3000-M8x200-100 Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-40g6x1000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x1200-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x1500-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x2000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x3000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1200-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1500-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x2000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x3000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1200-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1500-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x2000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x3000-M8x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-50g6x1000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x1200-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x1500-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x2000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x3000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1200-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1500-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x2000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x3000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1200-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1500-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x2000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x3000-M10x300-150 Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
Linear ShaftsWON ST
333 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

WON ST WBS / WBAS / WBCS Tapped Linear Shafts (dia. 10-50 mm)

Brand WON ST·Linear Shafts

Available part numbers (333)

WBS-10g6x1000-M4x100-50, WBS-10h5x1000-M4x100-50, WBS-10h6x1000-M4x100-50, WBS-12g6x1000-M4x100-50, WBS-12h5x1000-M4x100-50, WBS-12h6x1000-M4x100-50, WBS-13g6x1000-M4x100-50, WBS-13h5x1000-M4x100-50, WBS-13h6x1000-M4x100-50, WBS-16g6x1000-M5x150-75 + 323 more — see full table ↓

How to order

Send the WON ST part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
WBS-10g6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-10h5x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-10h6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12g6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12h5x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-12h6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13g6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13h5x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-13h6x1000-M4x100-50Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBS-16g6x1000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x1200-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x1500-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16g6x2000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1200-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x1500-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h5x2000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1200-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x1500-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-16h6x2000-M5x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBS-20g6x1000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x1200-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x1500-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x2000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20g6x3000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1200-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x1500-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x2000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h5x3000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1200-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x1500-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x2000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-20h6x3000-M6x150-75Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBS-25g6x1000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x1200-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x1500-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x2000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25g6x3000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1200-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x1500-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x2000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h5x3000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1200-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x1500-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x2000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-25h6x3000-M6x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBS-30g6x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30g6x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h5x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-30h6x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35g6x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h5x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1200-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x1500-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x2000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-35h6x3000-M8x200-100Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBS-40g6x1000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x1200-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x1500-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x2000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40g6x3000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1200-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x1500-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x2000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h5x3000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1200-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x1500-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x2000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-40h6x3000-M8x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBS-50g6x1000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x1200-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x1500-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x2000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50g6x3000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1200-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x1500-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x2000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h5x3000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1200-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x1500-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x2000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBS-50h6x3000-M10x300-150Series: WBS - Carbon steel / SUJ2 (standard) | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-10g6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-10h5x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-10h6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12g6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12h5x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-12h6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13g6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13h5x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-13h6x1000-M4x100-50Series: WBAS - SUS440C stainless | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBAS-16g6x1000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x1200-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x1500-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16g6x2000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1200-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x1500-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h5x2000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1200-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x1500-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-16h6x2000-M5x150-75Series: WBAS - SUS440C stainless | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBAS-20g6x1000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x1200-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x1500-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x2000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20g6x3000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1200-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x1500-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x2000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h5x3000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1200-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x1500-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x2000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-20h6x3000-M6x150-75Series: WBAS - SUS440C stainless | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBAS-25g6x1000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x1200-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x1500-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x2000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25g6x3000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1200-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x1500-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x2000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h5x3000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1200-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x1500-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x2000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-25h6x3000-M6x200-100Series: WBAS - SUS440C stainless | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBAS-30g6x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30g6x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h5x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-30h6x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35g6x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h5x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1200-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x1500-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x2000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-35h6x3000-M8x200-100Series: WBAS - SUS440C stainless | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBAS-40g6x1000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x1200-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x1500-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x2000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40g6x3000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1200-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x1500-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x2000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h5x3000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1200-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x1500-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x2000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-40h6x3000-M8x300-150Series: WBAS - SUS440C stainless | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBAS-50g6x1000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x1200-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x1500-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x2000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50g6x3000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1200-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x1500-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x2000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h5x3000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1200-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x1500-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x2000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBAS-50h6x3000-M10x300-150Series: WBAS - SUS440C stainless | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-10g6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: g6, -5 to -14 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-10h5x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: h5, 0 to -6 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-10h6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 10 mm | Tolerance: h6, 0 to -9 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12g6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12h5x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-12h6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 12 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13g6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13h5x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-13h6x1000-M4x100-50Series: WBCS - Hard chrome plated steel | Diameter: 13 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M4x0.7x6 @ 100, ends 50
WBCS-16g6x1000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x1200-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x1500-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16g6x2000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: g6, -6 to -17 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1200-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x1500-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h5x2000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h5, 0 to -8 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1200-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1200 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x1500-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 1500 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-16h6x2000-M5x150-75Series: WBCS - Hard chrome plated steel | Diameter: 16 mm | Tolerance: h6, 0 to -11 um | Length: 2000 mm | Tap: M5x0.8x9 @ 150, ends 75
WBCS-20g6x1000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x1200-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x1500-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x2000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20g6x3000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1200-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x1500-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x2000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h5x3000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1200-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x1500-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x2000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-20h6x3000-M6x150-75Series: WBCS - Hard chrome plated steel | Diameter: 20 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x10 @ 150, ends 75
WBCS-25g6x1000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x1200-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x1500-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x2000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25g6x3000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1200-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x1500-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x2000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h5x3000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1200-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x1500-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x2000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-25h6x3000-M6x200-100Series: WBCS - Hard chrome plated steel | Diameter: 25 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M6x1x12 @ 200, ends 100
WBCS-30g6x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30g6x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: g6, -7 to -20 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h5x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h5, 0 to -9 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-30h6x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 30 mm | Tolerance: h6, 0 to -13 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35g6x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h5x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1200-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x1500-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x2000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-35h6x3000-M8x200-100Series: WBCS - Hard chrome plated steel | Diameter: 35 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x15 @ 200, ends 100
WBCS-40g6x1000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x1200-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x1500-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x2000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40g6x3000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1200-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x1500-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x2000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h5x3000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1200-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x1500-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x2000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-40h6x3000-M8x300-150Series: WBCS - Hard chrome plated steel | Diameter: 40 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M8x1.25x18 @ 300, ends 150
WBCS-50g6x1000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x1200-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x1500-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x2000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50g6x3000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: g6, -9 to -25 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1200-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x1500-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x2000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h5x3000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h5, 0 to -11 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1200-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1200 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x1500-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 1500 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x2000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 2000 mm | Tap: M10x1.5x22 @ 300, ends 150
WBCS-50h6x3000-M10x300-150Series: WBCS - Hard chrome plated steel | Diameter: 50 mm | Tolerance: h6, 0 to -16 um | Length: 3000 mm | Tap: M10x1.5x22 @ 300, ends 150

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Linear Motion & Bearings →
