Wonkwang Air In-Line Heater (A-1 to A-11, 1-300 kW)

Wonkwang Air In-Line Heater (A-1 to A-11, 1-300 kW)

Duct and pipe-mounted air in-line heaters for heating compressed air or blower air, from compact 1 kW units to rotor-type 300 kW systems. Styles A-1 to A-11 cover straight, insulated, ring-blower and aluminium-body designs.

Key features

  • Straight, fully insulated sealed and rotor-type constructions
  • SUS304 and aluminium (AL) body versions
  • Ring-blower and blower-mounted system versions
  • Piping connections 10A-25A on A-10; 1-1/4 in. on line heaters
  • Single-phase or 3-phase 220V / 380V / 440V

Specifications

Brand Wonkwang Heating System
Medium Air
Capacity range 1-300 kW
Voltage 1-ph or 3-ph 220V / 380V / 440V
Body SUS304 or aluminium
Options Outlet temperature sensor, overheat sensor, solenoid valve
Source Wonkwang Heating System hot air blower and heater boards (A-series in-line heaters)
A-1 Type: Blower-mounted in-line system | Voltage: 3-ph 220/380/440V | Capacity: 3-14 kW
A-2 Type: In-line heater system | Voltage: 3-ph 220/380/440V | Capacity: 10-100 kW
A-3 Type: In-line heater system | Voltage: 3-ph 220/380/440V | Capacity: 10-100 kW
A-4 Type: Straight in-line | Voltage: 3-ph 220/380/440V | Capacity: 2-15 kW
A-5 Type: Ring-blower in-line | Voltage: 1-ph 220/380/440V | Capacity: 2-5 kW
A-6 Type: AL ring-blower line heater | Voltage: 1-ph 220/380/440V | Capacity: 2-5 kW
A-7 Type: SUS304 air line heater | Voltage: 3-ph 220/380/440V | Capacity: On request
A-8 Type: Fully insulated sealed system | Voltage: On request | Capacity: 5-15 kW
A-9 Type: Rotor type | Voltage: On request | Capacity: 15-300 kW
A-10 Type: In-line, 10A-25A piping | Voltage: On request | Capacity: 5-15 kW
A-11 Type: Compact in-line | Voltage: On request | Capacity: 1-5 kW
IN LINE 220V3KW 400L Type: Straight in-line, 400 mm body | Voltage: 220V | Capacity: 3 kW
AL LINE HEATER 220V 4KW Type: AL line heater | Voltage: 1-ph 220V | Capacity: 4 kW
LINE HEATER 380V 18KW Type: Line heater, 1-1/4 in. ports | Voltage: 3-ph 380V | Capacity: 18 kW
Air In-Line HeaterWonkwang Heating System
14 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Wonkwang Air In-Line Heater (A-1 to A-11, 1-300 kW)

Brand Wonkwang Heating System·Air In-Line Heater

Available part numbers (14)

A-1, A-2, A-3, A-4, A-5, A-6, A-7, A-8, A-9, A-10 + 4 more — see full table ↓

How to order

Send the Wonkwang Heating System part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
A-1Type: Blower-mounted in-line system | Voltage: 3-ph 220/380/440V | Capacity: 3-14 kW
A-2Type: In-line heater system | Voltage: 3-ph 220/380/440V | Capacity: 10-100 kW
A-3Type: In-line heater system | Voltage: 3-ph 220/380/440V | Capacity: 10-100 kW
A-4Type: Straight in-line | Voltage: 3-ph 220/380/440V | Capacity: 2-15 kW
A-5Type: Ring-blower in-line | Voltage: 1-ph 220/380/440V | Capacity: 2-5 kW
A-6Type: AL ring-blower line heater | Voltage: 1-ph 220/380/440V | Capacity: 2-5 kW
A-7Type: SUS304 air line heater | Voltage: 3-ph 220/380/440V | Capacity: On request
A-8Type: Fully insulated sealed system | Voltage: On request | Capacity: 5-15 kW
A-9Type: Rotor type | Voltage: On request | Capacity: 15-300 kW
A-10Type: In-line, 10A-25A piping | Voltage: On request | Capacity: 5-15 kW
A-11Type: Compact in-line | Voltage: On request | Capacity: 1-5 kW
IN LINE 220V3KW 400LType: Straight in-line, 400 mm body | Voltage: 220V | Capacity: 3 kW
AL LINE HEATER 220V 4KWType: AL line heater | Voltage: 1-ph 220V | Capacity: 4 kW
LINE HEATER 380V 18KWType: Line heater, 1-1/4 in. ports | Voltage: 3-ph 380V | Capacity: 18 kW
