YASKAWA DGP Isolator (Insulated DC Transmission Converter)

YASKAWA DGP Isolator (Insulated DC Transmission Converter)

DGP isolators that isolate drive analog I/O signals and reduce inductive noise.

Specifications

Accuracy ±0.25% of output span (23 °C)
Response time 0.5 s or less
Withstand voltage 2000 Vac for 60 s
Insulation resistance 20 MΩ min. (500 Vdc)
Cable length 4-20 mA: 100 m max.; 0-10 V: 50 m max.
Weight 350 g (60 g socket)
DGP2-4-4 Input: 0-10 V | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-732
DGP2-4-8 Input: 0-10 V | Output: 4-20 mA | Power supply: 100 Vac | Code no: 100-250-733
DGP2-8-4 Input: 4-20 mA | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-734
DGP2-3-4 Input: 0-5 V | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-731
DGP3-4-4 Input: 0-10 V | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-736
DGP3-4-8 Input: 0-10 V | Output: 4-20 mA | Power supply: 200 Vac | Code no: 100-250-737
DGP3-8-4 Input: 4-20 mA | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-738
DGP3-3-4 Input: 0-5 V | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-735
Signal IsolatorsYASKAWA
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA DGP Isolator (Insulated DC Transmission Converter)

Brand YASKAWA·Signal Isolators

Available part numbers (8)

DGP2-4-4, DGP2-4-8, DGP2-8-4, DGP2-3-4, DGP3-4-4, DGP3-4-8, DGP3-8-4, DGP3-3-4

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
DGP2-4-4Input: 0-10 V | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-732
DGP2-4-8Input: 0-10 V | Output: 4-20 mA | Power supply: 100 Vac | Code no: 100-250-733
DGP2-8-4Input: 4-20 mA | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-734
DGP2-3-4Input: 0-5 V | Output: 0-10 V | Power supply: 100 Vac | Code no: 100-250-731
DGP3-4-4Input: 0-10 V | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-736
DGP3-4-8Input: 0-10 V | Output: 4-20 mA | Power supply: 200 Vac | Code no: 100-250-737
DGP3-8-4Input: 4-20 mA | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-738
DGP3-3-4Input: 0-5 V | Output: 0-10 V | Power supply: 200 Vac | Code no: 100-250-735
