YASKAWA EUJ710 Harmonic Filter Module for D1000

Harmonic filter modules that are required standard configuration devices for D1000 models of 5 to 185 kW; select according to D1000 capacity and environmental specification.

Key features

Versions with environmental specifications (model KM) are available on request

Specifications

Use	Standard configuration device for D1000 5-185 kW (required)

EUJ710801		Code no: 100-115-243 \| For D1000 model: CIMR-DA2A0005 \| Rated current: 15 A \| Weight: 6.5 kg
EUJ710810		Code no: 100-091-897 \| For D1000 model: CIMR-DA2A0010 \| Rated current: 29 A \| Weight: 9 kg
EUJ710820		Code no: 100-091-898 \| For D1000 model: CIMR-DA2A0020 \| Rated current: 57 A \| Weight: 14 kg
EUJ710831		Code no: 100-115-244 \| For D1000 model: CIMR-DA2A0030 \| Rated current: 83 A \| Weight: 16 kg
EUJ710840		Code no: 100-091-915 \| For D1000 model: CIMR-DA2A0050 \| Rated current: 140 A \| Weight: 27 kg
EUJ710851		Code no: 100-115-249 \| For D1000 model: CIMR-DA2A0065 \| Rated current: 200 A \| Weight: 38 kg
EUJ710861		Code no: 100-115-250 \| For D1000 model: CIMR-DA2A0090 \| Rated current: 270 A \| Weight: 43 kg
EUJ710871		Code no: 100-110-486 \| For D1000 model: CIMR-DA2A0130 \| Rated current: 400 A \| Weight: 62 kg
EUJ710880		Code no: 100-106-328 \| For D1000 model: CIMR-DA4A0005 \| Rated current: 8 A \| Weight: 7 kg
EUJ710890		Code no: 100-106-329 \| For D1000 model: CIMR-DA4A0010 \| Rated current: 16 A \| Weight: 9 kg
EUJ710900		Code no: 100-106-330 \| For D1000 model: CIMR-DA4A0020 \| Rated current: 30 A \| Weight: 15 kg
EUJ710911		Code no: 100-115-245 \| For D1000 model: CIMR-DA4A0030 \| Rated current: 43 A \| Weight: 17 kg
EUJ710921		Code no: 100-115-246 \| For D1000 model: CIMR-DA4A0040 \| Rated current: 58 A \| Weight: 19 kg
EUJ710931		Code no: 100-115-247 \| For D1000 model: CIMR-DA4A0060 \| Rated current: 86 A \| Weight: 27 kg
EUJ710941		Code no: 100-115-248 \| For D1000 model: CIMR-DA4A0100 \| Rated current: 145 A \| Weight: 39 kg
EUJ710951		Code no: 100-110-487 \| For D1000 model: CIMR-DA4A0130 \| Rated current: 210 A \| Weight: 64 kg
EUJ710961		Code no: 100-110-488 \| For D1000 model: CIMR-DA4A0185 \| Rated current: 300 A \| Weight: 73 kg

Harmonic FiltersYASKAWA

17 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

YASKAWA EUJ710 Harmonic Filter Module for D1000

Brand YASKAWA·Harmonic Filters

Available part numbers (17)

EUJ710801, EUJ710810, EUJ710820, EUJ710831, EUJ710840, EUJ710851, EUJ710861, EUJ710871, EUJ710880, EUJ710890 + 7 more — see full table ↓

How to order

Send the YASKAWA part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
