YASKAWA R1000 Current Suppression Reactor

YASKAWA R1000 Current Suppression Reactor

Current suppression reactor that is a required standard configuration device for the R1000 power regenerative unit, connected between the input fuses and the R1000.

Key features

  • Select according to the R1000 model

Specifications

Use Standard configuration device for R1000 (required)
Terminals X, Y, Z inputs (from fuses) / R, S, T outputs (to R1000)
100-133-594 For R1000 model: CIMR-RA2A03P5 / CIMR-RA2A0005 | Voltage class: 200 V | Rated current: 15 A | Inductance: 0.31 mH | Weight: 1.5 kg
100-133-595 For R1000 model: CIMR-RA2A0007 | Voltage class: 200 V | Rated current: 20 A | Inductance: 0.15 mH | Weight: 1.5 kg
100-133-596 For R1000 model: CIMR-RA2A0010 / CIMR-RA2A0014 | Voltage class: 200 V | Rated current: 40 A | Inductance: 0.1 mH | Weight: 2.5 kg
100-133-597 For R1000 model: CIMR-RA2A0017 | Voltage class: 200 V | Rated current: 50 A | Inductance: 0.06 mH | Weight: 2.5 kg
100-133-598 For R1000 model: CIMR-RA2A0020 | Voltage class: 200 V | Rated current: 60 A | Inductance: 0.05 mH | Weight: 2.5 kg
100-133-599 For R1000 model: CIMR-RA2A0028 | Voltage class: 200 V | Rated current: 80 A | Inductance: 0.04 mH | Weight: 3 kg
100-133-600 For R1000 model: CIMR-RA2A0035 | Voltage class: 200 V | Rated current: 100 A | Inductance: 0.03 mH | Weight: 3 kg
100-107-397 For R1000 model: CIMR-RA2A0053 | Voltage class: 200 V | Rated current: 153 A | Inductance: 0.02 mH | Weight: 5.1 kg
100-107-398 For R1000 model: CIMR-RA2A0073 | Voltage class: 200 V | Rated current: 209 A | Inductance: 0.015 mH | Weight: 6.6 kg
100-107-399 For R1000 model: CIMR-RA2A0105 | Voltage class: 200 V | Rated current: 306 A | Inductance: 0.01 mH | Weight: 9 kg
100-107-390 For R1000 model: CIMR-RA4A03P5 / CIMR-RA4A0005 | Voltage class: 400 V | Rated current: 7.5 A | Inductance: 1.2 mH | Weight: 1.5 kg
100-107-391 For R1000 model: CIMR-RA4A0007 | Voltage class: 400 V | Rated current: 10 A | Inductance: 0.6 mH | Weight: 1.5 kg
100-107-392 For R1000 model: CIMR-RA4A0010 | Voltage class: 400 V | Rated current: 15 A | Inductance: 0.4 mH | Weight: 1.5 kg
100-107-393 For R1000 model: CIMR-RA4A0014 / CIMR-RA4A0017 | Voltage class: 400 V | Rated current: 25 A | Inductance: 0.3 mH | Weight: 2.5 kg
100-107-394 For R1000 model: CIMR-RA4A0020 | Voltage class: 400 V | Rated current: 30 A | Inductance: 0.2 mH | Weight: 2.5 kg
100-107-395 For R1000 model: CIMR-RA4A0028 | Voltage class: 400 V | Rated current: 40 A | Inductance: 0.15 mH | Weight: 2.5 kg
100-107-400 For R1000 model: CIMR-RA4A0035 | Voltage class: 400 V | Rated current: 50 A | Inductance: 0.12 mH | Weight: 3 kg
100-107-401 For R1000 model: CIMR-RA4A0043 | Voltage class: 400 V | Rated current: 60 A | Inductance: 0.1 mH | Weight: 4 kg
100-107-402 For R1000 model: CIMR-RA4A0053 | Voltage class: 400 V | Rated current: 75 A | Inductance: 0.08 mH | Weight: 5 kg
100-107-403 For R1000 model: CIMR-RA4A0073 | Voltage class: 400 V | Rated current: 100 A | Inductance: 0.06 mH | Weight: 5 kg
100-107-404 For R1000 model: CIMR-RA4A0105 | Voltage class: 400 V | Rated current: 161 A | Inductance: 0.04 mH | Weight: 9 kg
100-107-405 For R1000 model: CIMR-RA4A0150 | Voltage class: 400 V | Rated current: 237 A | Inductance: 0.03 mH | Weight: 15.1 kg
100-107-406 For R1000 model: CIMR-RA4A0210 | Voltage class: 400 V | Rated current: 326 A | Inductance: 0.02 mH | Weight: 17 kg
100-107-407 For R1000 model: CIMR-RA4A0300 | Voltage class: 400 V | Rated current: 466 A | Inductance: 0.013 mH | Weight: 25 kg
