[GGM] — K10H□BU Heavy-Duty Solid-Shaft Gearhead (for K10 200/400W Brushless Motor Unit, ø22 solid, 1/5~1/200)
Family ID: GGM-K10H-BU
GGM K10H□BU heavy-duty inline solid-shaft gearhead for K10 200/400W brushless motor units, with ø22 keyed output shaft (h7) and □110 flange (ø120 P.C.D). Deceleration ratios 1/5 to 1/200 (8 steps), allowed output torque up to 70 N·m, 81–90% efficiency; motor sold separately.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K10H5BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/5, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/5 | Output Speed Range: 20~600 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 2.9 N·m (200W) / 5.9 N·m (400W) brushless, AC type | Gearhead Efficiency: 90% | Allowed Overhang Load: 550 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×95 (set included) | ||
| K10H10BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/10, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/10 | Output Speed Range: 10~300 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 5.9 N·m (200W) / 11.7 N·m (400W) brushless, AC type | Gearhead Efficiency: 90% | Allowed Overhang Load: 550 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×95 (set included) | ||
| K10H15BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/15, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/15 | Output Speed Range: 6.7~200 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 8.8 N·m (200W) / 17.6 N·m (400W) brushless, AC type | Gearhead Efficiency: 90% | Allowed Overhang Load: 550 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×95 (set included) | ||
| K10H20BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/20, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/20 | Output Speed Range: 5~150 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 11.7 N·m (200W) / 23.4 N·m (400W) brushless, AC type | Gearhead Efficiency: 90% | Allowed Overhang Load: 550 N (at 10mm from shaft end) | Allowed Thrust Load: 200 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×95 (set included) | ||
| K10H30BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/30, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/30 | Output Speed Range: 3.3~100 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 16.8 N·m (200W) / 33.5 N·m (400W) brushless, AC type | Gearhead Efficiency: 86% | Allowed Overhang Load: 1000 N (at 10mm from shaft end) | Allowed Thrust Load: 300 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×110 (set included) | ||
| K10H50BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/50, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/50 | Output Speed Range: 2~60 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 28 N·m (200W) / 55.9 N·m (400W) brushless, AC type | Gearhead Efficiency: 86% | Allowed Overhang Load: 1000 N (at 10mm from shaft end) | Allowed Thrust Load: 300 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×110 (set included) | ||
| K10H100BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/100, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/100 | Output Speed Range: 1~30 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 52.7 N·m (200W) / 70 N·m (400W) brushless, AC type | Gearhead Efficiency: 81% | Allowed Overhang Load: 1400 N (at 10mm from shaft end) | Allowed Thrust Load: 400 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×120 (set included) | ||
| K10H200BU | GGM K10H□BU heavy-duty solid-shaft gearhead, ratio 1/200, ø22 keyed shaft, for K10 200/400W brushless motor unit | GGM | Type: Heavy-Duty Inline Solid-Shaft Gearhead (for K10 Brushless Motor Unit) | Deceleration Ratio: 1/200 | Output Speed Range: 0.5~15 r/min (with 100-3000 r/min motor) | Allowed Output Torque: 70 N·m (200W) / 70 N·m (400W) brushless, AC type | Gearhead Efficiency: 81% | Allowed Overhang Load: 1400 N (at 10mm from shaft end) | Allowed Thrust Load: 400 N | Output Shaft: ø22 solid (h7), key type | Flange: □110, P.C.D ø120, M6 tap | Fixing Bolt: M8 P1.25×120 (set included) |
