[GGM] — K35 BLDC Planetary Gearmotor KB3640S1 (Ø35, DC 12V, 1/5–1/721, with Brake)
Family ID: GGM-K35-3640-S1
GGM K35 Ø35 BLDC planetary gearmotor KB3640S1, DC 12V, 13 gear ratios from 1/5 to 1/721. integrated brake, PWM speed control (GUN-type controller), max output torque 12 kgf·cm, output rotates same direction as motor.
13 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| K35-0005-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/5, 900 rpm / 0.7 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/5 | Output Speed: 900 rpm (at max. eff.) | Output Torque: 0.7 kgf·cm | ||
| K35-0014-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/14, 321 rpm / 1.7 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/14 | Output Speed: 321 rpm (at max. eff.) | Output Torque: 1.7 kgf·cm | ||
| K35-0019-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/19, 237 rpm / 2.3 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/19 | Output Speed: 237 rpm (at max. eff.) | Output Torque: 2.3 kgf·cm | ||
| K35-0027-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/27, 167 rpm / 3.3 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/27 | Output Speed: 167 rpm (at max. eff.) | Output Torque: 3.3 kgf·cm | ||
| K35-0051-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/51, 88 rpm / 5.5 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/51 | Output Speed: 88 rpm (at max. eff.) | Output Torque: 5.5 kgf·cm | ||
| K35-0071-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/71, 63 rpm / 7.7 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/71 | Output Speed: 63 rpm (at max. eff.) | Output Torque: 7.7 kgf·cm | ||
| K35-0100-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/100, 45 rpm / 10.8 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/100 | Output Speed: 45 rpm (at max. eff.) | Output Torque: 10.8 kgf·cm | ||
| K35-0139-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/139, 32 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/139 | Output Speed: 32 rpm (at max. eff.) | Output Torque: 12 kgf·cm | ||
| K35-0189-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/189, 24 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/189 | Output Speed: 24 rpm (at max. eff.) | Output Torque: 12 kgf·cm | ||
| K35-0264-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/264, 17 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/264 | Output Speed: 17 rpm (at max. eff.) | Output Torque: 12 kgf·cm | ||
| K35-0369-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/369, 12 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/369 | Output Speed: 12 rpm (at max. eff.) | Output Torque: 12 kgf·cm | ||
| K35-0516-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/516, 8.7 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/516 | Output Speed: 8.7 rpm (at max. eff.) | Output Torque: 12 kgf·cm | ||
| K35-0721-KB3640S1 | K35 BLDC gearmotor KB3640S1, 1/721, 6.2 rpm / 12 kgf·cm (DC 12V) | GGM | Gear Ratio: 1/721 | Output Speed: 6.2 rpm (at max. eff.) | Output Torque: 12 kgf·cm |
