[GGM] — K30-2847 Series DC Planetary Geared Motor (ø30mm, 12/24V, 1/5–1/721)
DC GGM

[GGM] — K30-2847 Series DC Planetary Geared Motor (ø30mm, 12/24V, 1/5–1/721)

Family ID: GGM-K30-2847

GGM K30-2847 DC planetary geared motor, ø30mm frame, ø6mm shaft, 4-M3 flange mount (PCD ø24). Two windings (12V/24V), 13 planetary ratios 1/5 to 1/721; 110g.

26 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
K30-0005-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/5, 1260 rpm / 0.4 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/5 | Output Speed (max eff.): 1260 rpm | Output Torque (max eff.): 0.4 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 23.1 mm | Type: DC planetary geared motor
K30-0014-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/14, 450 rpm / 1 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/14 | Output Speed (max eff.): 450 rpm | Output Torque (max eff.): 1 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0019-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/19, 331 rpm / 1.3 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/19 | Output Speed (max eff.): 331 rpm | Output Torque (max eff.): 1.3 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0027-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/27, 233 rpm / 1.9 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/27 | Output Speed (max eff.): 233 rpm | Output Torque (max eff.): 1.9 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0051-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/51, 123 rpm / 3 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/51 | Output Speed (max eff.): 123 rpm | Output Torque (max eff.): 3 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0071-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/71, 88 rpm / 4.5 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/71 | Output Speed (max eff.): 88 rpm | Output Torque (max eff.): 4.5 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0100-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/100, 63 rpm / 6.5 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/100 | Output Speed (max eff.): 63 rpm | Output Torque (max eff.): 6.5 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0139-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/139, 45 rpm / 9 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/139 | Output Speed (max eff.): 45 rpm | Output Torque (max eff.): 9 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0189-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/189, 33 rpm / 11 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/189 | Output Speed (max eff.): 33 rpm | Output Torque (max eff.): 11 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0264-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/264, 23 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/264 | Output Speed (max eff.): 23 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0369-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/369, 17 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/369 | Output Speed (max eff.): 17 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0516-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/516, 12 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/516 | Output Speed (max eff.): 12 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0721-KD2847T1 GGM K30-2847 DC 12V planetary geared motor, ratio 1/721, 8.7 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T1 | Voltage: DC 12V | Gear Ratio: 1/721 | Output Speed (max eff.): 8.7 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 830 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0005-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/5, 1260 rpm / 0.5 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/5 | Output Speed (max eff.): 1260 rpm | Output Torque (max eff.): 0.5 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 23.1 mm | Type: DC planetary geared motor
K30-0014-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/14, 450 rpm / 1.2 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/14 | Output Speed (max eff.): 450 rpm | Output Torque (max eff.): 1.2 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0019-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/19, 331 rpm / 1.6 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/19 | Output Speed (max eff.): 331 rpm | Output Torque (max eff.): 1.6 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0027-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/27, 233 rpm / 2.4 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/27 | Output Speed (max eff.): 233 rpm | Output Torque (max eff.): 2.4 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 29.5 mm | Type: DC planetary geared motor
K30-0051-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/51, 123 rpm / 4 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/51 | Output Speed (max eff.): 123 rpm | Output Torque (max eff.): 4 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0071-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/71, 88 rpm / 5.5 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/71 | Output Speed (max eff.): 88 rpm | Output Torque (max eff.): 5.5 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0100-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/100, 63 rpm / 8 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/100 | Output Speed (max eff.): 63 rpm | Output Torque (max eff.): 8 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0139-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/139, 45 rpm / 11 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/139 | Output Speed (max eff.): 45 rpm | Output Torque (max eff.): 11 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 35.9 mm | Type: DC planetary geared motor
K30-0189-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/189, 33 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/189 | Output Speed (max eff.): 33 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0264-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/264, 23 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/264 | Output Speed (max eff.): 23 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0369-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/369, 17 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/369 | Output Speed (max eff.): 17 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0516-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/516, 12 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/516 | Output Speed (max eff.): 12 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
K30-0721-KD2847T2 GGM K30-2847 DC 24V planetary geared motor, ratio 1/721, 8.7 rpm / 12 kgf·cm @ max eff. GGM Motor: KD2847T2 | Voltage: DC 24V | Gear Ratio: 1/721 | Output Speed (max eff.): 8.7 rpm | Output Torque (max eff.): 12 kgf·cm | No-load Speed: 7300 rpm | Stall Torque: 870 gf·cm | Frame: ø30mm | Output Shaft: ø6mm, 4-M3 flange (PCD ø24) | Gearhead Length L: 42.3 mm | Type: DC planetary geared motor
