![[GGM] — KGV2-3640 BLDC Geared Motor, KB3640S1 (DC 12V, 9 ratios 1/60–1/660, F/R output)](https://img.prosourcemro.com/2026/06/0605-22-1024x856.png)
DC
GGM
[GGM] — KGV2-3640 BLDC Geared Motor, KB3640S1 (DC 12V, 9 ratios 1/60–1/660, F/R output)
Family ID: GGM-KGV2-3640-S1
GGM KGV2-3640 BLDC geared motor, KB3640S1 (DC 12V, no-load 5300 rpm). 9 ratios 1/60–1/660, F/R output shaft, PWM speed control with CW/CCW and brake, torque up to 20 kgf·cm.
18 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGV2-0060-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/60, F-TYPE | GGM | Gear Ratio: 1/60 | Output Speed: 75 rpm | Output Torque: 5.2 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0060-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/60, R-TYPE | GGM | Gear Ratio: 1/60 | Output Speed: 75 rpm | Output Torque: 5.2 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0070-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/70, F-TYPE | GGM | Gear Ratio: 1/70 | Output Speed: 64.2 rpm | Output Torque: 6 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0070-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/70, R-TYPE | GGM | Gear Ratio: 1/70 | Output Speed: 64.2 rpm | Output Torque: 6 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0090-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/90, F-TYPE | GGM | Gear Ratio: 1/90 | Output Speed: 50 rpm | Output Torque: 7.8 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0090-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/90, R-TYPE | GGM | Gear Ratio: 1/90 | Output Speed: 50 rpm | Output Torque: 7.8 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0105-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/105, F-TYPE | GGM | Gear Ratio: 1/105 | Output Speed: 42.8 rpm | Output Torque: 9 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0105-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/105, R-TYPE | GGM | Gear Ratio: 1/105 | Output Speed: 42.8 rpm | Output Torque: 9 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0135-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/135, F-TYPE | GGM | Gear Ratio: 1/135 | Output Speed: 33.3 rpm | Output Torque: 10.6 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0135-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/135, R-TYPE | GGM | Gear Ratio: 1/135 | Output Speed: 33.3 rpm | Output Torque: 10.6 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0200-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/200, F-TYPE | GGM | Gear Ratio: 1/200 | Output Speed: 22.5 rpm | Output Torque: 15.7 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0200-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/200, R-TYPE | GGM | Gear Ratio: 1/200 | Output Speed: 22.5 rpm | Output Torque: 15.7 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0350-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/350, F-TYPE | GGM | Gear Ratio: 1/350 | Output Speed: 12.8 rpm | Output Torque: 20 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0350-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/350, R-TYPE | GGM | Gear Ratio: 1/350 | Output Speed: 12.8 rpm | Output Torque: 20 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0500-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/500, F-TYPE | GGM | Gear Ratio: 1/500 | Output Speed: 9 rpm | Output Torque: 20 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0500-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/500, R-TYPE | GGM | Gear Ratio: 1/500 | Output Speed: 9 rpm | Output Torque: 20 kgf·cm | Output Shaft: R-TYPE | ||
| KGV2-0660-KB3640S1-F | KGV2-3640 BLDC KB3640S1 geared motor, 1/660, F-TYPE | GGM | Gear Ratio: 1/660 | Output Speed: 6.8 rpm | Output Torque: 20 kgf·cm | Output Shaft: F-TYPE | ||
| KGV2-0660-KB3640S1-R | KGV2-3640 BLDC KB3640S1 geared motor, 1/660, R-TYPE | GGM | Gear Ratio: 1/660 | Output Speed: 6.8 rpm | Output Torque: 20 kgf·cm | Output Shaft: R-TYPE |
