DC
GGM
[GGM] — KGP-3448-P2 Flange Geared DC Motor (DC 24V, 9000rpm base, 2 ratios 1/62-1/116)
Family ID: GGM-KGP3448-P2
GGM KGP-3448-P2 flange-mount geared DC motor, DC 24V (9000 rpm base motor). 2 gear ratios 1/62-1/116, output torque up to 6 kgf·cm, ø10.5 output bore with ø3 spring pin, 4-ø4.5 flange mounting. Output rotation same as motor.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KGP-0062-KD3448P2-FL | KGP-3448-P2 Flange geared, 1/62, 129rpm, 3.2kgf·cm | GGM | Gear Ratio: 1/62 | Output Speed: 129 rpm | Output Torque: 3.2 kgf·cm | Mount/Output: Flange, ø10.5 bore | ||
| KGP-0116-KD3448P2-FL | KGP-3448-P2 Flange geared, 1/116, 69rpm, 6kgf·cm | GGM | Gear Ratio: 1/116 | Output Speed: 69 rpm | Output Torque: 6 kgf·cm | Mount/Output: Flange, ø10.5 bore |
