Inverters (VFD)
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — FR-E700EX FR-E720EX Sensorless Servo Drive Unit (3-Phase 200V, for MM-GKR)
Family ID: MEL-FRE700EX-E720EX
FR-E700EX sensorless servo drive unit FR-E720EX, 3-phase 200V, 0.1-0.75kW, for MM-GKR PM motors. PM sensorless vector control (no encoder), point-table positioning (7 points), built-in RS-485, IP20 self-cooling.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| FR-E720EX-0.1K | FR-E700EX drive unit FR-E720EX 0.1kW, 3-ph 200V, for MM-GKR13 | MITSUBISHI ELECTRIC | Applied Motor: 0.1 kW · Rated Output Current: 0.8 A · Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) · Control: PM sensorless vector (high-freq superposition at low speed) · Carrier: 10kHz · Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg · Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link · Input: 3-ph 200-240V 50/60Hz · Enclosure: Closed IP20 · Cooling: Self-cooling · Mass: 0.5 kg · Depth (D): 80.5 mm | ||
| FR-E720EX-0.2K | FR-E700EX drive unit FR-E720EX 0.2kW, 3-ph 200V, for MM-GKR23 | MITSUBISHI ELECTRIC | Applied Motor: 0.2 kW · Rated Output Current: 1.5 A · Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) · Control: PM sensorless vector (high-freq superposition at low speed) · Carrier: 10kHz · Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg · Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link · Input: 3-ph 200-240V 50/60Hz · Enclosure: Closed IP20 · Cooling: Self-cooling · Mass: 0.5 kg · Depth (D): 80.5 mm | ||
| FR-E720EX-0.4K | FR-E700EX drive unit FR-E720EX 0.4kW, 3-ph 200V, for MM-GKR43 | MITSUBISHI ELECTRIC | Applied Motor: 0.4 kW · Rated Output Current: 3 A · Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) · Control: PM sensorless vector (high-freq superposition at low speed) · Carrier: 10kHz · Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg · Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link · Input: 3-ph 200-240V 50/60Hz · Enclosure: Closed IP20 · Cooling: Self-cooling · Mass: 0.7 kg · Depth (D): 112.5 mm | ||
| FR-E720EX-0.75K | FR-E700EX drive unit FR-E720EX 0.75kW, 3-ph 200V, for MM-GKR73 | MITSUBISHI ELECTRIC | Applied Motor: 0.75 kW · Rated Output Current: 5 A · Overload: 150% 60s / 200% 3s (motor rated current basis, inverse-time) · Control: PM sensorless vector (high-freq superposition at low speed) · Carrier: 10kHz · Positioning: point-table 7 points, 5120 pulses/rev, accuracy +/-1.8 deg · Communication: built-in RS-485 (Mitsubishi inverter / Modbus-RTU), option CC-Link · Input: 3-ph 200-240V 50/60Hz · Enclosure: Closed IP20 · Cooling: Self-cooling · Mass: 1.0 kg · Depth (D): 132.5 mm |
