Flow Sensors
Omron
[OMRON] — E8FC IoT Flow Sensor (Flow Rate + Temperature, IO-Link, PNP/NPN, COM2/COM3)
Family ID: OMRON-E8FC
OMRON E8FC Series IoT flow sensor for simultaneous measurement of flow rate and temperature. Detects cooling water, water-soluble coolant, and water-insoluble oil abnormalities. Liquid. PNP/NPN selectable. IO-Link Analog. E8FC-25SD: COM2. E8FC-25ST: COM3. Requires adapter (sold separately): E8FC-YA-R/N10A/15A/20A/25A (10~25A, R/NPT thread). M12 cable sold separately (XS5F/XS5W series).
10 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| E8FC-25SD | E8FC Flow+Temp IoT sensor IO-Link COM2 (38.4 kbps) | OMRON | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM2 (38.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative | ||
| E8FC-25ST | E8FC Flow+Temp IoT sensor IO-Link COM3 (230.4 kbps) | OMRON | Type: IoT Flow Sensor | Measurement: Flow rate + Temperature simultaneous | Medium: Liquid (cooling water / water-soluble coolant / water-insoluble oil) | Output: PNP/NPN selectable | Communication: IO-Link Analog | IO-Link Baud Rate: COM3 (230.4 kbps) | Connection: M12 connector (cable sold separately) | Required Adapter: E8FC-YA-R/N 10A/15A/20A/25A (sold separately) | Note: IO-Link IODD file required; contact OMRON representative | ||
| E8FC-YA-R10A | E8FC Adapter 10 A 3/8" R (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-N10A | E8FC Adapter 10 A 3/8" NPT (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 10 A | Nominal Diameter B: 3/8" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-R15A | E8FC Adapter 15 A 1/2" R (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-N15A | E8FC Adapter 15 A 1/2" NPT (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 15 A | Nominal Diameter B: 1/2" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-R20A | E8FC Adapter 20 A 3/4" R (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-N20A | E8FC Adapter 20 A 3/4" NPT (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 20 A | Nominal Diameter B: 3/4" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-R25A | E8FC Adapter 25 A 1" R (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: R (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides | ||
| E8FC-YA-N25A | E8FC Adapter 25 A 1" NPT (taper thread) | OMRON | Type: Adapter for E8FC (required for installation) | Nominal Diameter A: 25 A | Nominal Diameter B: 1" | Thread Type: NPT (taper thread) | Material: SUS304 | Compatible Sensor: E8FC-25SD / E8FC-25ST | Note: Sensor cannot be installed without adapter; same pipe diameter recommended on both sides |
