[OMRON] — R88M-1A AC Servomotor 1S-series Safety, 1500 r/min, 200/400 VAC

Family ID: OMRON-R88M1A-1500rpm

AC Servomotor 1S-series with Safety Functionality. Compatible with R88D-1SAN[]-ECT Servo Drives.

32 product codes available in this family

Product Codes & Specifications

Product Code	Description	Brand	Spec
R88M-1AM1K515T	R88M-1A 1500rpm 200 VAC 1.5 kW Straight shaft Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-O	R88M-1A 1500rpm 200 VAC 1.5 kW Straight shaft Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-B	R88M-1A 1500rpm 200 VAC 1.5 kW Straight shaft With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-B-O	R88M-1A 1500rpm 200 VAC 1.5 kW Straight shaft With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515TS2	R88M-1A 1500rpm 200 VAC 1.5 kW With key and tap Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-OS2	R88M-1A 1500rpm 200 VAC 1.5 kW With key and tap Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-BS2	R88M-1A 1500rpm 200 VAC 1.5 kW With key and tap With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515T-B-OS2	R88M-1A 1500rpm 200 VAC 1.5 kW With key and tap With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T	R88M-1A 1500rpm 200 VAC 2.7 kW Straight shaft Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-O	R88M-1A 1500rpm 200 VAC 2.7 kW Straight shaft Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-B	R88M-1A 1500rpm 200 VAC 2.7 kW Straight shaft With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-B-O	R88M-1A 1500rpm 200 VAC 2.7 kW Straight shaft With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715TS2	R88M-1A 1500rpm 200 VAC 2.7 kW With key and tap Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-OS2	R88M-1A 1500rpm 200 VAC 2.7 kW With key and tap Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-BS2	R88M-1A 1500rpm 200 VAC 2.7 kW With key and tap With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM2K715T-B-OS2	R88M-1A 1500rpm 200 VAC 2.7 kW With key and tap With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 200 VAC \| Rated Output: 2.7 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C	R88M-1A 1500rpm 400 VAC 1.5 kW Straight shaft Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-O	R88M-1A 1500rpm 400 VAC 1.5 kW Straight shaft Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-B	R88M-1A 1500rpm 400 VAC 1.5 kW Straight shaft With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-B-O	R88M-1A 1500rpm 400 VAC 1.5 kW Straight shaft With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515CS2	R88M-1A 1500rpm 400 VAC 1.5 kW With key and tap Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-OS2	R88M-1A 1500rpm 400 VAC 1.5 kW With key and tap Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-BS2	R88M-1A 1500rpm 400 VAC 1.5 kW With key and tap With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM1K515C-B-OS2	R88M-1A 1500rpm 400 VAC 1.5 kW With key and tap With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 1.5 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C	R88M-1A 1500rpm 400 VAC 3 kW Straight shaft Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-O	R88M-1A 1500rpm 400 VAC 3 kW Straight shaft Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: Straight shaft \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-B	R88M-1A 1500rpm 400 VAC 3 kW Straight shaft With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-B-O	R88M-1A 1500rpm 400 VAC 3 kW Straight shaft With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: Straight shaft \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015CS2	R88M-1A 1500rpm 400 VAC 3 kW With key and tap Without brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-OS2	R88M-1A 1500rpm 400 VAC 3 kW With key and tap Without brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: With key and tap \| Brake: Without brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-BS2	R88M-1A 1500rpm 400 VAC 3 kW With key and tap With brake Without oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: Without oil seal \| Safety: Built-in \| Series: 1S-series
R88M-1AM3K015C-B-OS2	R88M-1A 1500rpm 400 VAC 3 kW With key and tap With brake With oil seal	OMRON	Rated Speed: 1500 r/min \| Power Supply: 400 VAC \| Rated Output: 3 kW \| Shaft: With key and tap \| Brake: With brake \| Oil Seal: With oil seal \| Safety: Built-in \| Series: 1S-series
