[SMC] — JSY1500 5-Port Solenoid Valve (JSY1000-E, Plug-in for Ejector Manifold)
Family ID: SMC-JSY1500
SMC 5-port solenoid valve, JSY1000-E series (compact plug-in unit for ejector system manifold). Switching: 3-position Pressure Center. Seal type: rubber (elastomer, no metal seal option). Response time: 16 ms. Mass: 30 g. Rated coil voltage: DC24V (only). Coil power: 0.2W (energy-saving circuit built-in only). Operating frequency: 5 Hz max (3 Hz for 3-position). Manual operation: Non Lock Push or Push Turn Lock (driver type). Pilot exhaust method: individual exhaust. Surge voltage protection: diode (built-in). LED indicator lamp. This compact valve is designed exclusively for use with JJ5SY1-E10 ejector system integrated manifold base, supporting EtherCAT serial transmission (EX260). Application: material handling (pickers, small robots, pick&place, cartoners). Other variants (4-position dual 3-port N.O./mixed, 4-position 5-port for vacuum break, 2-position 3-port JSY110-B) available on request. CAT.KS11-119A.
1 product code available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| JSY1500 | 3-position Pressure Center, rubber seal, DC24V, 0.2W | SMC | Series: JSY1000-E | Body type: Plug-in single valve (for ejector system manifold) | Switching: 3-position Pressure Center | Seal: Rubber (elastomer) - only seal option | Response time: 16 ms | Mass: 30 g | Rated coil voltage: DC24V (only) | Coil power: 0.2W (energy-saving circuit built-in) | Allowable voltage variation: rated voltage ±10% | Manual operation: Non Lock Push / Push Turn Lock (driver type) | Pilot exhaust: individual exhaust | Operating frequency: 5 Hz (2-position) / 3 Hz (3-position) | Surge protection: diode (built-in) | Indicator lamp: LED | Manifold base: JJ5SY1-E10 series (EtherCAT EX260) |
