Cam Clutches
TSUBAKI
[Tsubaki] — LD Series Cam Clutch One-Way Clutch (Economy Type, 6200-Series OD)
Family ID: TSB-LD
Tsubaki Cam Clutch LD Series — economy type one-way clutch for easy installation and handling. Outer diameter matches 6200-series bearing dimensions (e.g. LD08 = 6208). Torque range: 5.88~49 N·m (0.6~5.0 kgf·m). Cost-effective solution for light-duty backstop and overrunning applications.
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| LD04 | LD04 — Bore Ø20 mm (6204) | Tsubaki | Series: LD | Type: Cam Clutch — Economy Type | Torque Range: 5.88~49 N·m (0.6~5.0 kgf·m) | Outer Diameter: Matches 6200-series bearing | Feature: Easy installation and handling | Application: Light-duty backstop, overrunning, low-torque indexing | Model: LD04 | Bore: Ø20 mm (6204) | ||
| LD05 | LD05 — Bore Ø25 mm (6205) | Tsubaki | Series: LD | Type: Cam Clutch — Economy Type | Torque Range: 5.88~49 N·m (0.6~5.0 kgf·m) | Outer Diameter: Matches 6200-series bearing | Feature: Easy installation and handling | Application: Light-duty backstop, overrunning, low-torque indexing | Model: LD05 | Bore: Ø25 mm (6205) | ||
| LD06 | LD06 — Bore Ø30 mm (6206) | Tsubaki | Series: LD | Type: Cam Clutch — Economy Type | Torque Range: 5.88~49 N·m (0.6~5.0 kgf·m) | Outer Diameter: Matches 6200-series bearing | Feature: Easy installation and handling | Application: Light-duty backstop, overrunning, low-torque indexing | Model: LD06 | Bore: Ø30 mm (6206) | ||
| LD07 | LD07 — Bore Ø35 mm (6207) | Tsubaki | Series: LD | Type: Cam Clutch — Economy Type | Torque Range: 5.88~49 N·m (0.6~5.0 kgf·m) | Outer Diameter: Matches 6200-series bearing | Feature: Easy installation and handling | Application: Light-duty backstop, overrunning, low-torque indexing | Model: LD07 | Bore: Ø35 mm (6207) | ||
| LD08 | LD08 — Bore Ø40 mm (6208) | Tsubaki | Series: LD | Type: Cam Clutch — Economy Type | Torque Range: 5.88~49 N·m (0.6~5.0 kgf·m) | Outer Diameter: Matches 6200-series bearing | Feature: Easy installation and handling | Application: Light-duty backstop, overrunning, low-torque indexing | Model: LD08 | Bore: Ø40 mm (6208) |
