Cam Clutches
TSUBAKI
[Tsubaki] — MG Series Cam Clutch One-Way Clutch (High Torque)
Family ID: TSB-MG
Tsubaki Cam Clutch MG Series — compact high-torque one-way clutch. Torque range: 314~176,000 N·m (32~18,000 kgf·m). Compact design with high torque capacity. One-way torque transmission; freewheels in reverse direction. Suitable for heavy-duty backstop, overrunning, and indexing applications.
9 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MG300 | MG300 — 314 N·m (32 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG300 | Rated Torque: 314 N·m (32 kgf·m) | ||
| MG400 | MG400 — 750 N·m (76 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG400 | Rated Torque: 750 N·m (76 kgf·m) | ||
| MG500 | MG500 — 1500 N·m (153 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG500 | Rated Torque: 1500 N·m (153 kgf·m) | ||
| MG600 | MG600 — 3000 N·m (306 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG600 | Rated Torque: 3000 N·m (306 kgf·m) | ||
| MG700 | MG700 — 6000 N·m (612 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG700 | Rated Torque: 6000 N·m (612 kgf·m) | ||
| MG750 | MG750 — 10000 N·m (1020 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG750 | Rated Torque: 10000 N·m (1020 kgf·m) | ||
| MG800 | MG800 — 30000 N·m (3060 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG800 | Rated Torque: 30000 N·m (3060 kgf·m) | ||
| MG900 | MG900 — 80000 N·m (8160 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG900 | Rated Torque: 80000 N·m (8160 kgf·m) | ||
| MG1000 | MG1000 — 176000 N·m (17952 kgf·m) | Tsubaki | Series: MG | Type: Cam Clutch (One-Way Clutch) — Compact High Torque | Torque Range: 314~176,000 N·m (32~18,000 kgf·m) | Function: Transmits torque in one direction; freewheels in reverse | Application: Heavy-duty backstop, overrunning clutch, indexing | Model: MG1000 | Rated Torque: 176000 N·m (17952 kgf·m) |
