Cam Clutches
TSUBAKI
[Tsubaki] — ML Series Cam Clutch One-Way Clutch (Cam & Roller)
Family ID: TSB-ML
Tsubaki Cam Clutch ML Series — cam & roller structure for easy mounting of various power transmission components. Torque range: 0~2,300 N·m (7~235 kgf·m). Standard type (no dust seal) and 2GD type (with dust seal) available. Suitable for backstop, overrunning, and indexing applications.
24 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| ML15 | ML15 — Standard (No Dust Seal) | Bore Ø15 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML15 | Bore: Ø15 mm | Dust Seal: No (Standard) | ||
| ML15-2GD | ML15 — With Dust Seal (2GD) | Bore Ø15 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML15-2GD | Bore: Ø15 mm | Dust Seal: Yes (2GD) | ||
| ML20 | ML20 — Standard (No Dust Seal) | Bore Ø20 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML20 | Bore: Ø20 mm | Dust Seal: No (Standard) | ||
| ML20-2GD | ML20 — With Dust Seal (2GD) | Bore Ø20 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML20-2GD | Bore: Ø20 mm | Dust Seal: Yes (2GD) | ||
| ML25 | ML25 — Standard (No Dust Seal) | Bore Ø25 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML25 | Bore: Ø25 mm | Dust Seal: No (Standard) | ||
| ML25-2GD | ML25 — With Dust Seal (2GD) | Bore Ø25 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML25-2GD | Bore: Ø25 mm | Dust Seal: Yes (2GD) | ||
| ML30 | ML30 — Standard (No Dust Seal) | Bore Ø30 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML30 | Bore: Ø30 mm | Dust Seal: No (Standard) | ||
| ML30-2GD | ML30 — With Dust Seal (2GD) | Bore Ø30 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML30-2GD | Bore: Ø30 mm | Dust Seal: Yes (2GD) | ||
| ML35 | ML35 — Standard (No Dust Seal) | Bore Ø35 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML35 | Bore: Ø35 mm | Dust Seal: No (Standard) | ||
| ML35-2GD | ML35 — With Dust Seal (2GD) | Bore Ø35 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML35-2GD | Bore: Ø35 mm | Dust Seal: Yes (2GD) | ||
| ML40 | ML40 — Standard (No Dust Seal) | Bore Ø40 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML40 | Bore: Ø40 mm | Dust Seal: No (Standard) | ||
| ML40-2GD | ML40 — With Dust Seal (2GD) | Bore Ø40 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML40-2GD | Bore: Ø40 mm | Dust Seal: Yes (2GD) | ||
| ML45 | ML45 — Standard (No Dust Seal) | Bore Ø45 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML45 | Bore: Ø45 mm | Dust Seal: No (Standard) | ||
| ML45-2GD | ML45 — With Dust Seal (2GD) | Bore Ø45 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML45-2GD | Bore: Ø45 mm | Dust Seal: Yes (2GD) | ||
| ML50 | ML50 — Standard (No Dust Seal) | Bore Ø50 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML50 | Bore: Ø50 mm | Dust Seal: No (Standard) | ||
| ML50-2GD | ML50 — With Dust Seal (2GD) | Bore Ø50 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML50-2GD | Bore: Ø50 mm | Dust Seal: Yes (2GD) | ||
| ML55 | ML55 — Standard (No Dust Seal) | Bore Ø55 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML55 | Bore: Ø55 mm | Dust Seal: No (Standard) | ||
| ML55-2GD | ML55 — With Dust Seal (2GD) | Bore Ø55 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML55-2GD | Bore: Ø55 mm | Dust Seal: Yes (2GD) | ||
| ML60 | ML60 — Standard (No Dust Seal) | Bore Ø60 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML60 | Bore: Ø60 mm | Dust Seal: No (Standard) | ||
| ML60-2GD | ML60 — With Dust Seal (2GD) | Bore Ø60 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML60-2GD | Bore: Ø60 mm | Dust Seal: Yes (2GD) | ||
| ML70 | ML70 — Standard (No Dust Seal) | Bore Ø70 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML70 | Bore: Ø70 mm | Dust Seal: No (Standard) | ||
| ML70-2GD | ML70 — With Dust Seal (2GD) | Bore Ø70 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML70-2GD | Bore: Ø70 mm | Dust Seal: Yes (2GD) | ||
| ML80 | ML80 — Standard (No Dust Seal) | Bore Ø80 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML80 | Bore: Ø80 mm | Dust Seal: No (Standard) | ||
| ML80-2GD | ML80 — With Dust Seal (2GD) | Bore Ø80 mm | Tsubaki | Series: ML | Type: Cam & Roller One-Way Clutch | Torque Range: 0~2,300 N·m (7~235 kgf·m) | Variants: Standard (no dust seal) / 2GD (with dust seal) | Application: Backstop, overrunning, indexing — easy power transmission component mounting | Model: ML80-2GD | Bore: Ø80 mm | Dust Seal: Yes (2GD) |
