Pressure Reducing Valves
Yuken
[Yuken] — Balancing Valve (RBG-03/06)
Family ID: YUK-PC-PR-RBG
Pressure Reducing and Relieving Valves. Combined pressure reducing and counter-balance functions. Max. operating pressure: 14 MPa (03) / 25 MPa (06). Pressure adjustment range: 0.6–13.5 MPa (03) / 0.8–24.5 MPa (06). Max. flow: 50/125 L/min. Internal or external (-R) drain. Sub-plate mounting.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| RBG-03-10 | Balancing Valve RBG-03, sub-plate, internal drain | Yuken | Type: Pressure Reducing and Relieving Valve | Mounting: Sub-plate | Valve Size: 03 | Drain: Internal | Max. Operating Pressure: 14 MPa | Pressure Adjustment Range: 0.6–13.5 MPa | Max. Flow: 50 L/min | Relief Flow: 50 L/min | Drain Flow: 0.6–1 L/min | Mass: 4.2 kg | Design No.: 10 | ||
| RBG-03-R-10 | Balancing Valve RBG-03-R, sub-plate, external drain | Yuken | Type: Pressure Reducing and Relieving Valve | Mounting: Sub-plate | Valve Size: 03 | Drain: External (-R) | Max. Operating Pressure: 14 MPa | Pressure Adjustment Range: 0.6–13.5 MPa | Max. Flow: 50 L/min | Relief Flow: 50 L/min | Drain Flow: 0.6–1 L/min | Mass: 4.2 kg | Design No.: 10 | ||
| RBG-06-10 | Balancing Valve RBG-06, sub-plate, internal drain | Yuken | Type: Pressure Reducing and Relieving Valve | Mounting: Sub-plate | Valve Size: 06 | Drain: Internal | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: 0.8–24.5 MPa | Max. Flow: 125 L/min | Relief Flow: 125 L/min | Drain Flow: 1.5–2 L/min | Mass: 11 kg | Design No.: 10 | ||
| RBG-06-R-10 | Balancing Valve RBG-06-R, sub-plate, external drain | Yuken | Type: Pressure Reducing and Relieving Valve | Mounting: Sub-plate | Valve Size: 06 | Drain: External (-R) | Max. Operating Pressure: 25 MPa | Pressure Adjustment Range: 0.8–24.5 MPa | Max. Flow: 125 L/min | Relief Flow: 125 L/min | Drain Flow: 1.5–2 L/min | Mass: 11 kg | Design No.: 10 |
