Pressure Reducing Valves
Yuken
[Yuken] — Pressure Reducing Valve (RG-03/06/10)
Family ID: YUK-PC-PR-RG
Pressure Reducing Valves · Pressure Reducing and Check Valves. Max. operating pressure: 21 MPa. Pressure adjustment range: B (0.7–7) / C (3.5–14) / H (7–20.5) MPa. Max. flow up to 250 L/min (size 10). Pressure Reducing Valve, Sub-plate mounting.
9 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| RG-03-B-22 | Pressure Reducing Valve RG-03-B, Sub-plate, range B | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No | ||
| RG-03-C-22 | Pressure Reducing Valve RG-03-C, Sub-plate, range C | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No | ||
| RG-03-H-22 | Pressure Reducing Valve RG-03-H, Sub-plate, range H | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 03 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 50 L/min (at 21 MPa primary) | Mass: 4.5 kg | Design No.: 22 | Check Valve: No | ||
| RG-06-B-22 | Pressure Reducing Valve RG-06-B, Sub-plate, range B | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No | ||
| RG-06-C-22 | Pressure Reducing Valve RG-06-C, Sub-plate, range C | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No | ||
| RG-06-H-22 | Pressure Reducing Valve RG-06-H, Sub-plate, range H | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 06 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 125 L/min (at 21 MPa primary) | Mass: 6.8 kg | Design No.: 22 | Check Valve: No | ||
| RG-10-B-20 | Pressure Reducing Valve RG-10-B, Sub-plate, range B | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: B (0.7–7 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No | ||
| RG-10-C-20 | Pressure Reducing Valve RG-10-C, Sub-plate, range C | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: C (3.5–14 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No | ||
| RG-10-H-20 | Pressure Reducing Valve RG-10-H, Sub-plate, range H | Yuken | Type: Pressure Reducing Valve | Mounting: Sub-plate | Valve Size: 10 | Pressure Adjustment Range: H (7–20.5 MPa) | Max. Operating Pressure: 21 MPa | Max. Flow: up to 250 L/min (at 21 MPa primary) | Mass: 11.0 kg | Design No.: 20 | Check Valve: No |
