[YUKEN] - CBY14N Thin Hydraulic Cylinder (Double Rod)
Family ID: YK-CBY14N
YUKEN CBY14 Series thin hydraulic cylinder. The overall length is about 1/3 of a conventional cylinder, so it can be installed even in tight spaces that are difficult for conventional cylinders. Light and compact design with an integrated cylinder tube and cover, the body using a special aluminum alloy. Usable up to 16 MPa depending on the operating pressure and number of cycles. Bore sizes 32-100 mm. Cushion: none (N). Standard enumerated strokes. Double rod configuration.
60 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| CBY14N-32-5 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-32-10 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-32-15 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-32-20 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-32-25 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-32-30 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-32-35 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-32-40 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-32-45 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-32-50 | CBY14N thin hydraulic cylinder, double rod, 32mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 32 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-32-N-50-[/T]-[/G]-[/L] | ||
| CBY14N-40-5 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-40-10 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-40-15 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-40-20 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-40-25 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-40-30 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-40-35 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-40-40 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-40-45 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-40-50 | CBY14N thin hydraulic cylinder, double rod, 40mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 40 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-40-N-50-[/T]-[/G]-[/L] | ||
| CBY14N-50-5 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-50-10 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-50-15 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-50-20 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-50-25 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-50-30 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-50-35 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-50-40 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-50-45 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-50-50 | CBY14N thin hydraulic cylinder, double rod, 50mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 50 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 2.5x10^6 cycles / 12 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-50-N-50-[/T]-[/G]-[/L] | ||
| CBY14N-63-5 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-63-10 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-63-15 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-63-20 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-63-25 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-63-30 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-63-35 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-63-40 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-63-45 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-63-50 | CBY14N thin hydraulic cylinder, double rod, 63mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 63 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-63-N-50-[/T]-[/G]-[/L] | ||
| CBY14N-80-5 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-80-10 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-80-15 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-80-20 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-80-25 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-80-30 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-80-35 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-80-40 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-80-45 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-80-50 | CBY14N thin hydraulic cylinder, double rod, 80mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 80 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-80-N-50-[/T]-[/G]-[/L] | ||
| CBY14N-100-5 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 5mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 5 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-5-[/T]-[/G]-[/L] | ||
| CBY14N-100-10 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 10mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 10 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-10-[/T]-[/G]-[/L] | ||
| CBY14N-100-15 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 15mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 15 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-15-[/T]-[/G]-[/L] | ||
| CBY14N-100-20 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 20mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 20 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-20-[/T]-[/G]-[/L] | ||
| CBY14N-100-25 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 25mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 25 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-25-[/T]-[/G]-[/L] | ||
| CBY14N-100-30 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 30mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 30 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-30-[/T]-[/G]-[/L] | ||
| CBY14N-100-35 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 35mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 35 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-35-[/T]-[/G]-[/L] | ||
| CBY14N-100-40 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 40mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 40 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-40-[/T]-[/G]-[/L] | ||
| CBY14N-100-45 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 45mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 45 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-45-[/T]-[/G]-[/L] | ||
| CBY14N-100-50 | CBY14N thin hydraulic cylinder, double rod, 100mm bore, 50mm stroke | YUKEN | Series: CBY14N (thin/compact hydraulic cylinder) | Rod Configuration: Double rod | Bore: 100 mm | Stroke: 50 mm (standard) | Cushion: None (N) - fixed | Rated Pressure: 14 MPa @ 9.0x10^5 cycles / 10 MPa @ 1.0x10^7 cycles | Proof Pressure: 20 MPa | Max Usable Pressure: up to 16 MPa (depending on operating pressure & cycles) | Min Operating Pressure: 0.3 MPa | Speed Range: 8-100 mm/s | Stroke Tolerance: 0 to +0.8 mm | Rod End Thread Tolerance: JIS B0211-6H/6g | Packing: 3: FKM (petroleum/phosphate-ester/W-O/O-W fluids; NOT water-glycol) / 6: HNBR std (petroleum/water-glycol/W-O/O-W fluids; NOT phosphate-ester) | Support (selectable): SD, LD, FA | Rod End Thread: T: male (both ends male thread for double rod) | Port: no symbol: Rc thread / G: G thread (SD support only) | Lock Nut: no symbol: none / L: 1 pc lock nut (not selectable with female rod-end thread) | Ambient Temp: -10 to +70 C (no condensation) | Full Code: CBY14N-[3/6]-[SD/LD/FA]-100-N-50-[/T]-[/G]-[/L] |
